GENERAL ABOUT THE SERVICE MODE
MODE
n.16 Enable factory preset mode
n.17 Select display units for pressures and temperature
n.18 Factory test
MODE
n 19 Show software version of IMUX CPU
n 20 Show instrument holder & AUX-input signals
n 21 Show active instrument hose ID-code
n 22 Show active instrument hose identification signal
n 23 Show active instrument switch/sensor signal
n 24 Show console syringe location hose ID-code
n 25 Show console syringe location hose identification signal
n 26 Show console syringe switch signal
n 27 Show IMUX on/off valve signals
n 28 Show IMUX other output signals
n 29 Show air / water pressure difference
n 30 Show active instrument drive/cooling air pressure
n.31 Select the service mode navigation type
n 32 Show active instrument spray air pressure
n.33 Factory test
n 34 Show active instrument spray water pressure
n.35 Factory test
n.36 Set mode of IMUX membrane operation
n.37 Disable turbine contamination prevention system
n 38 Show internal water or air pressure
Technical Manual
Table 1: MAIN control system related service modes
SERVICE MODE FUNCTION
Table 2: Instrument MUX related service modes
SERVICE MODE FUNCTION
Chapter C - SERVICE MODE
DISPLAY/RANGE
A = perform service mode preset
B = perform user mode preset
1 = bar (n.nn) and Celsius (default)
2 = kPa (nnn) and Celsius
3 = PSI (nn.n) and Fahrenheit
4 = PSI (nn.n) and Celsius
-
DISPLAY/RANGE
n.nn
¦ ¦¦¦¦¦; long =active (on), short =in
holder (off)
---- = no active instrument
selected
nn = ID code
0 = no hose connected
0 - 255
0 - 255
0 = no hose, nn = ID code
0 - 255
0 - 255
¦¦¦¦¦¦ (long = on, short = off)
¦¦¦¦¦¦ (long = on, short = off)
(±) n.nn bar; nnn kPa; nn.n PSI
n.nn bar; nnn kPa; nn.n PSI
0 = normal
2 = accelerated (default)
n.nn bar; nnn kPa; nn.n PSI
n.nn bar; nnn kPa; nn.n PSI
1 = continuously on when unit is
idle (default)
0 = off when unit is idle
1 = enabled (factory default)
0 = disabled
A (A) = show internal air pressure
H (B) = show internal water pres-
sure
X n.nn bar; X nnn kPa; X nn.n
PSI
Planmeca Compact i C-5
page
C-21
C-21
C-21
page
C-22
C-22
C-22
C-22
C-22
C-22
C-23
C-23
C-23
C-23
C-23
C-23
C-24
C-24
C-24
C-24
C-24
C-24
C-25
C-25
