HELP MESSAGES
Help Code
HE 50 No glass in the glass holder. The glass sensor
does not recognise the glass when pressing
the glass fill key.
HE 51
The bowl is above the patient chair when driv-
ing the chair up.
HE 52 The patient chair can not be driven upwards
because the emergency switch of the side
delivery arm is released.
HE 53 The patient chair can not be driven down-
wards because the emergency switch of the
side delivery arm is released.
HE 54 Glass is inserted in the glass holder.
HE 60
Water management system (WMS): Container
almost empty in domestic water supply mode.
HE 61
WMS: Container almost empty in Clean Water
mode.
HE 62 WMS: The Container switch is turned off.
HE 63
Cuspidor door is open.
HE 64 Fill the container with disinfectant over the
upper sensor.
HE 65
Fill the container with water over the upper
sensor.
HE 66 Wait 8 hours or switch the unit off for the night.
HE 70
The brushless micromotor is stucked or bro-
ken.
HE 80
Headrest safety operation: length movement
blocked or closing gap has obstacles
HE 95 The automatic position of the patient chair has
been programmed to a height which cannot be
reached at the moment because the legrest is
unlocked or the armrests are blocking the
movement.
HE 99 The unit has been switched off without per-
forming the long flushing after water has been
used. The help message will disappear after
the long flushing is performed.
End Flushing is completed. After flushing (short,
long or Waterline Cleaning System): Remove
the syringe from the flushing holder and return
it back. If the syringe is already removed,
return it back to the flushing holder. This
ensures that no water will flow from the
syringes after flushing.
Door Cuspidor door is open.
Technical Manual
Meaning
Chapter D - HELP & ERROR MESSAGES
Action or Explanation
Place a glass to the glass holder. Or change
the setting of the service mode 115.
Move the bowl to the rest position.
Remove the glass.
Reduce water usage for a moment.
Reduce water use and fill up the container as
soon as possible.
Switch on the container switch.
Close the door.
Check that nothing is blocking the headrest
movement. The headrest can be driven nor-
mally after the possible obstruction has been
removed.
This help message can be disabled, see page
C-38 for details.
Close the door.
