Chapter D - HELP & ERROR MESSAGES

3 DETAILED DESCRIPTION OF ERROR MESSAGES

3.1 General error messages

E 1.nn Output short circuit on MCB
All valve and extra outputs on the MCB are short-circuit protected. Additionally, the MCB CPU
system is able to read the signal levels on the output pins. Therefore the following detailed
information can be presented about the possible short circuit.
E 1.01
E 1.02
E 1.03
E 1.04
E 1.05
E 1.06
E 1.07
E 1.08
E 1.09
E 1.10
E 1.11
E 1.12
E 1.13
E 1.14
These errors can only be detected when the circuit is active.
Disconnect the valve or output indicated and check if the error disappears. Otherwise the
problem must be in the cable, or as the last possibility, on the MCB. If the error does not dis-
appear even if the valve cable at connector P16 on the MCB is disconnected, then the MCB
must be replaced. Advanced: Replace both IC37 and IC36 on the MCB.
E 2.nn Main Control PCB output open circuit warning
The following list indicates which output is causing the trouble;
E 2.01
E 2.02
E 2.03
E 2.04
E 2.05
E 2.06
E 2.07
E 2.08
E 2.09
E 2.10
E 2.11
E 2.12
E 2.13
E 2.14
These errors can be detected when the circuit is dead.
Disconnect the connectors at the end of the indicated bad valve (load). Measure with an ohm-
meter that the valve resistance is in the range 50-300Ω. Disconnect the valve connector P16
on the MCB and check the condition on the indicated valve cable wires. Check that both the
disconnected wires are OK all the way to P16.
D-10 Planmeca Compact i
Main water valve short circuit
Main air valve short circuit
Bowl rinse valve short circuit
Cup filling valve short circuit
Water flush valve short circuit
Separator pulse valve short circuit (only with Microvac's)
Ejector valve short circuit (only if defined as an option)
Extra out 1 short circuit (High volume membrane valve, reserved)
Extra out 2 short circuit (Saliva suction membrane valve, reserved)
Extra out 3 short circuit (Reserved)
Separator start signal/Microvac's start valve short circuit
Assistant syringe water valve short circuit
Separator alarm reset signal short circuit
PLANET output (ELMP) short circuit
Incoming water valve open circuit
Incoming air valve open circuit
Bowl rinse valve open circuit
Cup filling valve open circuit
reserved
Separator pulse valve open circuit (only with Microvac's)
reserved
reserved
reserved
reserved
Separator start signal open circuit / Microvac valve open circuit
Assistant syringe water valve open circuit
Separator alarm reset signal open circuit
reserved
