SERVICE MODE DETAILED DESCRIPTION
n.102 Disable dry spray mode when using Plus Package (0, 1, 2)
n 103 Show the dental unit type (nn)
NOTE
n.104 Instrument multiplexer additional water valve control (0, 1,
n.105 Enable/disable instrument places ( IIIII signal )
Technical Manual
This service mode is for disabling dry spray mode from the instruments when using Plus
Package. 0 = dry spray mode enabled, 1 = dry spray mode disabled, Plus package signal
tones, 2 = dry spray mode disabled, normal signal tones.
The factory default is 0 (dry spray mode enabled).
First digit shows type of Main PCB:
2 = Planmeca Compact i
Second digit shows IMUX version:
0 = no IMUX
1 = IMUX PCB version E or older
2 = IMUX PCB version F-G (1.08.x)
3 = IMUX PCB version F-G (1.09.x or 1.10.x)
4 = IMUX PCB version H or newer
Third digit shows dental unit type:
0 = Prostyle Compact
1 = Planmeca Compact e
2 = Planmeca Compact i
Fourth digit shows patient chair type:
0 = no patient chair
1 = Prostyle Compact chair without legrest or legrest up
2 = Prostyle chair with legrest down
3 = WE'S lifter
4 = Planmeca Compact e chair
5 = Planmeca Compact i chair with fixed legrest; or automatic legrest up
6 = Planmeca Compact i chair with 510 automatic legrest; in automatic state
7 = Planmeca Compact i chair with 460 automatic legrest; in automatic state
8 = Planmeca Compact e with swivelled position recognition and fixed legrest
9 = Planmeca Compact e with swivelled position recognition and automatic legrest
A = Planmeca Compact e swivelled to 90° with automatic legrest
The Planmeca Compact i chair with automatic legrest can be either number 5
or 6/7; it is number 5 if the legrest is locked up, and it is number 6/7 when the
legrest is moving synchronously with the backrest.
2, A)
This service mode is for enabling the instrument multiplexer additional water valve control.
0 = disabled
1 = reserved for factory use
2 = enabled (default)
0 - 2 are for IMUX PCB version G
A = automatic
A is for IMUX PCB version H
In this service mode you can enable/disable instrument places. The different setting combina-
tion can be scrolled and selected by using the "A"- and "B"-keys. The display shows a short
line on the place where the instrument place is disabled. Note, that the syringe cannot be
disabled.
