SERVICE MODE DETAILED DESCRIPTION

2.4 Control panel related service modes

n 45
n 46
n 47
n 48
n 49
Technical Manual
Show control panel type/AUX input for branch 1 (n = -, 0, 1,
2, 3)
This service mode shows the type of the control panel connected to the MCB branch 1 (nor-
mally the dentist's console control panel). A dash (-) indicates either that no control panel is
connected to this branch, the cable to the panel is loose or faulty, or that the panel itself does
not respond. The numbers 0-3 show that the panel is communicating with the MCB. 0 =
nurse's panel, 1 = doctor's panel, 2 = nurse's plus panel, 3 = doctor's plus panel.
Show control panel type/AUX input for branch 2 (n = -, 0, 1,
2, 3)
This service mode shows the type of the control panel connected to the MCB branch 2. See
explanation above.
Show control panel key code for branch 1 (n.n)
This service mode shows which key is pressed on the control panel connected to MCB
branch 1 (normally the dentist's console control panel). The left side digit (of the decimal
point) indicates the row, the right side digit indicates the column.
Show control panel key code for branch 2 (n.n)
This service mode shows which key is pressed on the control panel connected to MCB
branch 2. See explanation above.
Display test
This service mode turns on all individual LEDs and display segments on the control panel(s).
Can be used to check that all displays work properly.
