Figure 85: Captive Screws To Secure Risers To The Motherboard - Oracle FS1-2 Customer Service Manual

Flash storage system
Hide thumbs Also See for FS1-2:
Table of Contents

Advertisement

Figure 85: Captive screws to secure risers to the motherboard

Legend
1 Riser 3 with latch
2 Riser 2
To install riser 3, lock the latch to secure the riser to the Controller
motherboard.
Controller Replacement Procedures
3 Riser 1
4 Captive screws
118
