Drive Enclosure Components - Oracle FS1-2 Customer Service Manual

Legend
1 Top cover (with service label)
2 LED assembly
3 Fan modules
4 CUID
5 Energy storage modules (ESMs)
6 Air filter
7 Motherboard cable kit
8 Filler panels for DIMM slots
Related Links
Replace a Controller Riser
Replace Controller Air Filter
Replace a Controller DIMM
Replace a Controller Energy Storage Module (ESM)
Replace a Controller Fan Module
Replace a Controller HBA
Replace a Controller Power Supply
Replace a Controller Riser

Drive Enclosure Components

When replacing a component, you must know its part number and whether it is
hot serviceable. Having that information helps you to order the correct
replacement component and to determine whether you can replace the
component yourself. To locate part numbers, open
(https://support.oracle.com/handbook_private/index.html). The part numbers are
listed in the Oracle FS1 Flash Storage System components list.
The Drive Enclosure chassis is a field replaceable unit (FRU). The remaining
components of both Drive Enclosure types are customer replaceable units (CRU).
Drive Enclosure CRUs are hot serviceable.
Warning: Do not power‑cycle a Drive Enclosure. Power‑cycling a Drive Enclosure
impacts the primary and secondary data paths in the Drive Enclosure and puts
user data at risk.
The following figure shows the CRUs in the DE2-24P Drive Enclosure.
Introduction to Oracle FS1-2 System Service Procedures
9 DIMMs
10 Fan compartment
11 PDB risers
12 ESM backplane boards
13 Power supply
14 PDB duct
15 Air duct
16 HBA
Oracle System Handbook
17 Riser
18 Battery
19 NV-DIMM
20 Heat sink
21 CPU
22 PDB cover
