Figure 9: Exploded view of Pilot replaceable components
Legend
1. Pilot top cover
2 Air baffle
3 Battery
4 Heat sink
5 Fan modules
6 Front Indicator Module (FIM)
7 Energy Storage Module (ESM) for Oracle 12 Gb/s
SAS PCIe RAID HBA that goes into PCIe slot 4
8 SAS HDDs
Introduction to Oracle FS1-2 System Service Procedures
9 SAS HBA
10 Risers
11 DIMMs
12 Power supplies
13 CPU
14 USB OSA flash drive
15 Motherboard
16 Disk backplane boards
30
