Oracle FS System Hardware Specifications

Oracle FS System Hardware Specifications
An Oracle Flash Storage System is an assembly of Pilots, Controllers, Drive
Enclosures, power distribution units (PDUs), racks, and cables. Replication
Engines are an optional component of the Oracle FS System.
The following table indicates the basic components that constitute an Oracle
Flash Storage System.

Table 16: Basic components of an Oracle Flash Storage System

Component
Pilot
Controller
Drive Enclosure
PDU
Rack
Oracle Flash Storage System
Two Pilots for failover and failback
•
Management commands flow from the active Pilot to the
•
Controllers
Two Controllers for failover and failback
•
Provide network I/O access to customer facilities and
•
provides a storage fabric interface between all Drive
Enclosures and other Controllers.
1 to 30. The two types of Drive Enclosure are the
•
DE2-24P Drive Enclosure and the DE2-24C Drive
Enclosure.
Used as back-end storage for the Oracle FS Systems.
•
Two PDUs are required in each rack that is used for the
•
installation of rack-ready Oracle FS Systems.
PDUs are built-in to the Oracle racks.
•
At least one rack.
•
Note: The number of racks is based on the number of Drive
Enclosures and whether there are any Replication Engines
included in the system.
The number of racks depends on the number and the distribution of
the hardware components.
