C 1
HAPTER
Introduction to Oracle FS1-2 System Service
Procedures

Oracle FS System Service Procedures

Controller Components

When replacing a component, you must know its part number and whether it is
hot serviceable. Having that information helps you to order the correct
replacement component and to determine whether you can replace the
component yourself. To locate part numbers, open
(https://support.oracle.com/handbook_private/index.html). The part numbers are
listed in the Oracle FS1 Flash Storage System components list.
The Controller is a two rack-unit (2U) server and consists of several replaceable
components. Many Controller components are customer replaceable (CRUs),
while others are field replaceable units (FRUs) that require Oracle Customer
Support to perform the replacement. Also, some components are hot-serviceable,
meaning that they can be replaced, while the Controller is powered on. Some of
the Controller component replacement procedures require the Controller to be
powered off and/or removed from the rack. The following table provides a
summary of the Controller FRUs and CRUs.

Table 2: Controller components and descriptions

Controller component
4 GB NVDIMM
16 GB DIMM module
Air filter
Battery
Central processing unit (CPU)
Disk backplane
Energy storage module (ESM)
Fan module
Controller identification display (CUID)
HBA [Sun Storage: 16 Gb/s Fibre Channel (FC) PCI-e]
Oracle System Handbook
Type Hot
serviceable
FRU No
CRU No
CRU Yes
FRU No
FRU No
FRU No
FRU No
CRU No
FRU No
CRU No
20
