Close Pilot Top Cover - Oracle FS1-2 Customer Service Manual

Legend
Note: The three locking mechanisms that secure the riser in position on the
Pilot motherboard include:
Note: If you had removed the fan module (FM-0), replace the fan module
back in the fan compartment.
Note: Ensure that the rear bracket on the internal SAS HBA card in PCIe
slot 4 is connected to the slot in the Pilot chassis side wall. If the bracket is
not connected, remove the riser and reposition it so that the rear bracket
connects to the side wall, and then gently press the riser into the
motherboard connector.

Close Pilot Top Cover

1 Place the top cover of the Pilot onto the chassis.
Tip: Place the top cover down so that it hangs over the back of the Pilot by
about 13 mm (0.5 inches) and the side latches align with the slots in the
sides of the Pilot chassis.
Note: There are three latching tabs on the sides of the Pilot top cover, two
on the right side and one on the left side when viewing the Pilot from the
front. There is also a latch on the underside of the top cover in the front left
corner near the release button.
2 Check both sides of the Pilot chassis to ensure that the four corners of the
top cover are fully down and flush with the chassis.
Note: If the cover corners are not flush with the Pilot chassis, slide the
cover towards the back of the chassis until you can position the cover
correctly.
Note: If the top cover is not correctly positioned before attempting to slide
the cover forward, the internal latch that is on the underside of the cover
might be damaged.
1 Slide card retainer
2 Riser
3 PCIe riser lever
4 Retention clip that secures the riser faceplate
Slide card retainer that secures the riser to the Pilot.
•
Retention clip that secures the riser faceplate.
•
PCIe riser lever that secures the riser to the PCIe slot on the Pilot
•
motherboard.
Pilot Replacement Procedures
195
