Figure 5: DE2-24P Drive Enclosure CRUs

Legend
1 Drives
2 Power cooling module 0
3 Power cooling module 1
The following figure shows the CRUs in the DE2-24C Drive Enclosure.
Introduction to Oracle FS1-2 System Service Procedures
4 I/O module 0
5 I/O module 1
25
