Page 1 StorageTek SL150 Modular Tape Library Interface Reference Manual Part Number: E51473-03 Julyl 2017 Submit comments about this document to STP_FEEDBACK_US@ORACLE.COM.
Page 2 Oracle Corporation and its affiliates disclaim any liability for any damages caused by use of this software or hardware in dangerous applications.
Page 3: Table Of Contents
List of Figures .......................... 7 List of Tables ..........................9 Preface ............................13 Access to Oracle Support ..................... 13 General Information ......................15 Serial Attached SCSI ........................ 15 The Fibre Channel Standard ..................... 16 Overview ..........................16 Implementation ........................16 Related Publications .........................
Page 4 Initialize Element Status ......................30 Initialize Element Status With Range ..................31 Inquiry ............................. 32 Standard Inquiry Data (HP Bridged) ................... 34 Standard Inquiry Data (IBM Bridged) .................. 37 Supported Pages ......................... 40 Unit Serial Number Page ..................... 41 Device Identification Page (HP Bridged) ................42 Device Identification Page (IBM Bridged) ................
Page 5 Fibre Channel Port Control Page (HP Bridged) ..............111 SAS Port Control Page (HP Bridged) ................. 114 SAS Phy Control and Discover Mode Subpage (HP Bridged) ..........116 SAS Shared Control Mode Subpage (HP Bridged) ............. 119 SAS Enhanced Phy Control Subpage (HP Bridged) ............120 Informational Exceptions TapeAlert Control Page .............
Page 6 Report LUNs Data Definition .................... 213 Report Target Port Groups (HP Bridged) ................214 Report Target Port Group Data Definitions ............... 215 Target Port Group Descriptor Data ..................215 Target Port Descriptor Data ....................217 Request Sense ........................218 Sense Data ........................219 Request Sense Data Definitions ..................
Page 7: List Of Figures
List of Figures FIGURE A-1 Non-Partitioned 1 Module Library with No Reserved Cells and the Standard Mailslot Configuration 243 Non-Partitioned 2 Module Library with No Reserved Cells and the Expanded Mailslot FIGURE A-2 Configuration 244 FIGURE A-3 Non-Partitioned 10 Module Library with 3 Reserved Cells and the Standard Mailslot Con- figuration 245 FIGURE A-4 Non-Partitioned 15 Module Library with 3 Reserved Cells and the Standard Mailslot Con-...
Page 8 8 SL150 Interface Reference Manual Julyl 2017...
Page 9: List Of Tables
List of Tables TABLE 3-1 Reserve/Release Management Method ..............22 TABLE 3-2 Persistent Reservation Management Method .............. 23 6-Byte Command Descriptor Block................26 TABLE 4-1 TABLE 4-2 10-Byte Command Descriptor Block ................26 TABLE 4-3 12-byte Command Descriptor Block ................26 TABLE 4-4 Control Byte.......................
Page 10 TABLE 4-42 Fibre Channel Port Control Page ................87 TABLE 4-43 SAS Port Control Page....................90 TABLE 4-44 SAS Phy Control and Discover Mode Subpage ............92 TABLE 4-45 SAS Phy Mode Descriptor Data .................. 93 TABLE 4-46 Informational Exceptions TapeAlert Page..............95 TABLE 4-47 Element Address Assignment Mode Page ..............
Page 11 TABLE 4-96 Persistent Reserve Out Parameter List ..............177 TABLE 4-97 Persistent Reserve Out Service Actions and Valid Parameters........178 TABLE 4-98 Service Action Reservation Key Information............. 178 TABLE 4-99 Position to Element Command ................. 179 TABLE 4-100 Prevent/Allow Medium Removal Command ............180 TABLE 4-101 Read Element Status Command ................
Page 12 12 SL150 Interface Reference Manual Julyl 2017...
Page 13: Preface
The SL150 library supports SCSI commands over a Fibre Channel interface (FC) or Serial Attached SCSI interface (SAS). Access to Oracle Support Oracle customers have access to electronic support through My Oracle Support. For information, visit http://www.oracle.com/pls/topic/lookup?ctx=acc&id=info visit http://www.oracle.com/pls/topic/lookup?ctx=acc&id=trs...
Page 14 14 SL150 Interface Reference Manual Julyl 2017...
Page 15: General Information
General Information This manual describes the SCSI Media Changer (SMC) Command set for Oracle's StorageTek SL150 Modular Tape Library System. The SL150 library uses designated tape drives as the interface to the library or partition. The bridged tape drive determines the destination for commands based on the Logical Unit Number (LUN) that is sent with the command: •...
Page 16: The Fibre Channel Standard
The Fibre Channel Standard 2. Targets: A device (SL150 library tape drives) containing logical units and target ports that receives requests for processing and sends responses to an initiator. The target device for this document is an HP LTO-5, HP LTO-6, IBM LTO-6 or IBM LTO-7 tape drive.
Page 17: Related Publications
Related Publications Related Publications For your convenience, the following section lists publications that provide information about the interfaces and libraries mentioned in this manual. Listed publications are subject to change without notice. Publication Part Number American National Standard Dictionary for X3/TR-1-82 Information Processing Systems SCSI–3 Primary Commands (SPC)
Page 18 Related Publications 18 SL150 Interface Reference Manual Julyl 2017...
Page 19: Host Application Best Practices
Host Application Best Practices Running on Both Fibre Channel or SAS Ports When the drive has 2 ports, Oracle recommends that Host Application treat the second SL150 drive port as a fail over port. The library may report a CHECK CONDITION to a command received on one port, when the other port is already busy with a library command.
Page 20: Address Installed Drives Only
Drive Element Addressing Mode Configuration • A SCSI MODE SENSE command requesting the Element Address Assignment page will end in Good status. The total number of data transfer elements reported will include empty drive bays. • A SCSI READ ELEMENT STATUS command that includes an empty drive slot will end in Good status.
Page 21: Operation And Configuration Details
Operation and Configuration Details This chapter provides details for operation and configuration that are important while writing host applications. Multiple Initiator Support The library architecture supports multiple initiators with the following details: • Unit - Reserve and Release commands are supported. Persistent Reserve commands are also supported.
Page 22: Table 3-1 Reserve/Release Management Method
Device Reservations TABLE 3-1 Reserve/Release Management Method Action when Reserved by a different Initiator Command HP Bridged Drive IBM Bridged Drive Initialize Element (07h) Conflict Conflict Initialize Element with Range (37h/E7h) Conflict Conflict Inquiry (12h) Allowed Allowed Log Sense (4Dh) Allowed Allowed Mode Select (15h/55h)
Page 23: Table 3-2 Persistent Reservation Management Method
Device Reservations TABLE 3-2 Persistent Reservation Management Method Library is Reserved by a different Initiator with a Persistent Reservation Registered Initiators ALL Registrants or Non-Registered Exclusive Access Exclusive Access Command Initiators Reservation Registrants Only Initialize Element Status (07h) Conflict Conflict Allowed Initialize Element Status w/Range (37h/E7h) Conflict...
Page 24 Device Reservations TABLE 3-2 Persistent Reservation Management Method Library is Reserved by a different Initiator with a Persistent Reservation Registered Initiators ALL Registrants or Non-Registered Exclusive Access Exclusive Access Command Initiators Reservation Registrants Only Test Unit Ready (00h) Allowed Allowed Allowed HP Bridged Tape Drive Conflict...
Page 25: Command Set
Command Set This chapter lists and describes the small computer system interface (SCSI) command set for serial attached SCSI (SAS) and Fibre Channel (FC) interfaces to the SL150 Modular Library System. TABLE 4-5 contains a list of the commands, command codes, and page numbers that contain a description of the command.
Page 26: Table 4-1 6-Byte Command Descriptor Block
Implementation Requirements • 12–Byte commands (TABLE 4-3) The first byte in the command descriptor block contains an operation code. TABLE 4-1 6-Byte Command Descriptor Block Byte Group Code Command Code Reserved Command Parameters (MSB) Command Parameters (LSB) Control Byte TABLE 4-2 10-Byte Command Descriptor Block Byte Operation Code Reserved...
Page 27: Control Byte
Implementation Requirements Control Byte The control byte is the last byte of every Command Descriptor Block and has the following structure: TABLE 4-4 Control Byte Byte 5, 9, or 11 Vendor Specific Reserved NACA Flag Link • Vendor Specific Provides additional information about the device or a command. •...
Page 28: List Of Supported Commands
List of Supported Commands List of Supported Commands TABLE 4-5 Supported Commands Command and Page Number Hex Code Initialize Element Status on page 30 Initialize Element Status With Range on page 31 37/E7 Inquiry on page 32 Log Sense on page 50 Mode Select (6) on page 56 Mode Select (10) on page 78 Mode Sense (6) on page 100...
Page 29: Scsi Command Status
SCSI Command Status SCSI Command Status Good Good status (00h) indicates that the device successfully completed the command. Check Condition Check Condition status (02h) occurs when any error, unit exception, or abnormal condition generates sense data. The initiator should issue a Request Sense command following a Check Condition status to determine the nature of the error.
Page 30: Initialize Element Status
Initialize Element Status Initialize Element Status The host uses the Initialize Element Status command (07h) to request an inventory of the cartridge tapes held in the library. The library accepts this command for compatibility, but does not perform any action. At power-on the library performs an audit of and maintains the inventory during operations.
Page 31: Initialize Element Status With Range
Initialize Element Status With Range Initialize Element Status With Range The Initialize Element Status With Range command (37h and E7h) is a request from the host to perform an inventory of a portion of the cartridge tapes within the library. The library accepts this command for compatibility but does not perform any action.
Page 32: Inquiry
Inquiry Inquiry The Inquiry command (12h) requests that the library send to the initiator information regarding the library’s parameters. The Inquiry data returned for the Standard Inquiry page and the Inquiry Device Identification Page depend on the bridged tape drive. Note –...
Page 33 Inquiry Allocation Length Allocation lengths for the standard inquiry data and VPD pages: (continued) • 24h = Standard Inquiry Data Length (IBM Bridged Tape Drive) • 4Ah = Standard Inquiry Data Length (HP Bridged Tape Drive) • 08h = Supported Pages Length •...
Page 34: Standard Inquiry Data (Hp Bridged)
Inquiry Standard Inquiry Data (HP Bridged) TABLE 4-9 shows the format of the Standard Inquiry Data for an HP Bridged Tape Drive. TABLE 4-9 Standard Inquiry Data (HP Bridged) Byte Peripheral Qualifier Peripheral Device Type RMB (1) Reserved (0) Version (05h) Reserved (0) Norm HiSup...
Page 35 Inquiry Standard Inquiry Data Definitions (HP Bridged): Peripheral Qualifier The library returns a value of: • 000b= Indicating the specified peripheral device type is currently connected to this logical unit. • 011b = If the command is sent to an unsupported logical unit. (b = binary notation) Peripheral Device Type The library returns a value of:...
Page 36 Inquiry MChngr The library is not embedded in or attached to a medium transport element and returns a value of 0. ADDR16 The library returns a value of 0. WBUS16 The library returns a value of 0. SYNC The library returns a value of 0. CmdQue •...
Page 37: Standard Inquiry Data (Ibm Bridged)
Inquiry Standard Inquiry Data (IBM Bridged) TABLE 4-10 shows the format of the Standard Inquiry Data for an IBM Bridged Tape Drive. TABLE 4-10 Standard Inquiry Data (IBM Bridged) Byte Peripheral Qualifier Peripheral Device Type RMB (1) Reserved (0) Version (05h) Reserved (0) Norm HiSup...
Page 38 Inquiry Standard Inquiry Data Definitions (IBM Bridged): Peripheral Qualifier The library returns a value of: • 000b= Indicating the specified peripheral device type is currently connected to this logical unit. • 011b = If the command is sent to an unsupported logical unit. (b = binary notation) Peripheral Device Type The library returns a value of: •...
Page 39 Inquiry CmdQue Command Queuing 1b indicates the library supports command queuing. Vendor Identification Contains the ASCII character sequence “STK” followed by blanks. If the specified logical unit is not supported, this field contains all blanks. Product Identification Contains the ASCII character sequence “SL150” followed by blanks. Product Revision Level Contains an ASCII character sequence that represents the product revision.
Page 40: Supported Pages
Inquiry Supported Pages TABLE 4-11 shows the format of the Supported Pages. TABLE 4-11 Supported Pages Byte Peripheral Qualifier Peripheral Device Type Page Code (00h) Reserved (00h) Additional Page Length Supported Page (00h) Serial Number Page (80h) Device Identification Page (83h) SCSI Ports Page (88h) Vendor Specific Device Capabilities Page (C8h) (HP LTO-6 Bridged Drive only) Inquiry: Supported Pages Definitions:...
Page 41: Unit Serial Number Page
Inquiry Unit Serial Number Page TABLE 4-12 shows the format of the Unit Serial Number P. TABLE 4-12 Unit Serial Number Page Byte Peripheral Qualifier Peripheral Device Type Page Code (80h) Reserved (00h) Additional Page Length (12h) (MSB) Unit Serial Number (LSB) Unit Serial Number Page Definitions: Peripheral Qualifier...
Page 42: Device Identification Page (Hp Bridged)
Inquiry Device Identification Page (HP Bridged) TABLE 4-13 shows the format of the Device Identification Page (HP Bridged Tape Drive). TABLE 4-13 Device Identification Page Data (HP Bridged) Byte Peripheral Qualifier Peripheral Device Type Page Code (83h) Reserved (00h) Additional Page Length (42h) T10 Vendor Identifier Protocol Identifier (0) Code Set (2)
Page 43 Inquiry Device Identification Page Definitions (HP Bridged): Peripheral Qualifier The library returns a value of: • 000b= Indicating the specified peripheral device type is currently connected to this logical unit. • 011b = If the command is sent to an unsupported logical unit. (b = binary notation) Peripheral Device Type The library returns a value of:...
Page 44: Table 4-14 Ieee Registered Name
Inquiry TABLE 4-14 IEEE Registered Name Bits (MSB) (LSB) IEEE Company ID Vendor Specific Identifier 00 10 4f (h) Different for every bridged drive 44 SL150 Interface Reference Manual Julyl 2017...
Page 45: Device Identification Page (Ibm Bridged)
Inquiry Device Identification Page (IBM Bridged) TABLE 4-15 shows the format of the Device Identification Page (IBM Bridged Tape Drive). TABLE 4-15 Device Identification Page Data (IBM Bridged) Byte Peripheral Qualifier Peripheral Device Type Page Code (83h) Reserved (00h) Additional Page Length (3Ah) T10 Vendor Identifier Protocol Identifier (0) Code Set (2)
Page 46 Inquiry Device Identification Page Definitions: Peripheral Qualifier The library returns a value of: • 000b= Indicating the specified peripheral device type is currently connected to this logical unit. • 011b = If the command is sent to an unsupported logical unit. (b = binary notation) Peripheral Device Type The library returns a value of:...
Page 47: Scsi Ports Page
Inquiry SCSI Ports Page TABLE 4-16 shows the format of the SCSI Ports Page. TABLE 4-16 SCSI Ports Page Data Byte Peripheral Qualifier Peripheral Device Type Page Code (88h) Reserved (00h) Additional Page Length (MSB) SCSI Port Identification Descriptor (LSB) (MSB) SCSI Port Identification Descriptor (included if the drive has 2 ports and both ports are enabled)
Page 48: Table 4-17 Scsi Port Identification Descriptor Data
Inquiry SCSI Port Identification Descriptor Data TABLE 4-17 SCSI Port Identification Descriptor Data Byte Reserved (00h) Reserved (00h) 2 to 3 (MSB) Relative Port Identifier (LSB) 4 to 9 (MSB) Reserved (00h) (LSB) 10 to 11 (MSB) Target Port Descriptor Length (0Ch) (LSB) Protocol Identifier (0h or 6h) Code Set (1)
Page 49: Specific Device Capabilities Page (Hp Lto6 Bridged Tape Drive)
Inquiry Specific Device Capabilities Page (HP LTO6 Bridged Tape Drive) TABLE 4-18 shows the format of the Vendor Specific Device Capabilities Page (HP LTO-6 Bridged Tape Drive). Note – The Vendor Specific Device Capabilities page is only supported when the bridged drive is an HP LTO-6 drive. TABLE 4-18 Vendor Specific Device Capabilities Page (HP LTO-6 Bridged Tape Drive) Byte Peripheral Qualifier...
Page 50: Log Sense
Log Sense Log Sense The Log Sense command (4Dh) enables the library to report its error logs and statistics to the initiator. TABLE 4-19 Log Sense Command Byte Operation Code (4Dh) Ignored Reserved (0) PPC (0) SP (0) Page Code Reserved (00h) Reserved (00h) (MSB)
Page 51: Supported Pages Format Page
Log Sense Supported Pages Format Page The Supported Pages Format page lists all the Log Sense page codes supported by the library. TABLE 4-20 Supported Pages Format Page Byte Page Code (00h) Reserved (00h) (MSB) Page Length (03h) (LSB) Supported Pages Page Code (00h) Last n Errors Events Page Code (07h) Informational Exceptions TapeAlert Page Code (2Eh) Julyl 2017...
Page 52: Last N Errors Events Page
Log Sense Last n Errors Events Page The Last n Errors Events page provides a list of the most recent errors events logged on the library. Each event is an ASCII string that includes a time stamp, a fault symptom code (FSC), and an optional mechanism. Note –...
Page 53: Informational Exceptions Tapealert Page
Log Sense Informational Exceptions TapeAlert Page The Informational Exceptions TapeAlert page is read from the library at a minimum • At the beginning of a write/read job occurring on a device inside the library, even if media is not loaded in that device •...
Page 54: Table 4-23 Tapealert Flags
Log Sense Informational Exceptions TapeAlert Page Definitions: Parameter Code A 2-byte field which represents the TapeAlert Flag number. Disable Update is always 0, which indicates that the target updates the log parameter value instead of the initiator. Disable Save is always 1, which indicates saving the log is not supported. Target Save Disable is always 0.
Page 55 Log Sense TABLE 4-23 TapeAlert Flags (Continued) Code Flag Name Type 000Ch Unexpected Volume 000Dh Pick Retry 000Eh Place Retry 000Fh Load Retry 0010h Door Open 0011h Import/Export Element Fault 0012h Magazine Inaccessible 0013h Obsolete 0014h Obsolete 0015h Media Changer Offline 0016h Data Transfer Device Offline 0017h...
Page 56: Mode Select (6)
Mode Select (6) Mode Select (6) The 6-byte Mode Select command (15h) enables an initiator to specify certain operating parameters for the library. The library uses the saved or default versions of these parameters to configure itself during power-on or after a logical unit reset. The mode values sent to the library apply to all initiators.
Page 57 Mode Select (6) Parameter List Length The parameter list length field specifies the length in bytes of the mode parameter list that shall be contained in the data out sent by the host. The parameter list length is the sum of the length of the mode page header and one or more mode pages.
Page 58: Mode Select (6) Data
Mode Select (6) Mode Select (6) Data The initiator must provide mode parameter data in a parameter list including: • “Mode Select (6) Parameter Header” on page 58 • “Fibre Channel Disconnect/Reconnect Page (HP Bridged)” on page 59 • “SAS Disconnect/Reconnect Page (HP Bridged)” on page 61 •...
Page 59: Fibre Channel Disconnect/Reconnect Page (Hp Bridged)
Mode Select (6) Fibre Channel Disconnect/Reconnect Page (HP Bridged) TABLE 4-26 shows the format of the Mode Sense Fibre Channel Disconnect/ Reconnect page. TABLE 4-26 Fibre Channel Disconnect/Reconnect Page Byte Page Code (02h) Page length (0Eh) Buffer Full Ratio Buffer Empty Ratio 4 to 5 (MSB) Bus Inactivity Limit...
Page 60 Mode Select (6) Connect Time Limit The field indicates the maximum duration of a single interconnect tenancy, measured in increments of 128 transmission words. • 0000h indicates that there is no connect time limit. Maximum Burst Size This field indicates the maximum size of FCP_DATA IU that the device server shall transfer to the initiator or request from the initiator.
Page 61: Sas Disconnect/Reconnect Page (Hp Bridged)
Mode Select (6) SAS Disconnect/Reconnect Page (HP Bridged) TABLE 4-27 shows the format of the Mode Sense Serial Attached SCSI Disconnect/ Reconnect page. TABLE 4-27 SAS Disconnect/Reconnect Page Byte Page Code (02h) Page Length (0Eh) Reserved (00h) Reserved (00h) (MSB) Bus Inactivity Time Limit (LSB) Reserved (00h)
Page 62 Mode Select (6) Maximum Burst Size For read data, this field contains the maximum amount of data in 512-byte increments that is transferred during a connection by an SSP target port per I_T_L_Q nexus without transferring at least one frame for a different I_T_L_Q nexus.
Page 63: Fibre Channel Logical Unit Page (Hp Bridged)
Mode Select (6) Fibre Channel Logical Unit Page (HP Bridged) TABLE 4-28 shows the format of the Fibre Channel Logical Unit page. TABLE 4-28 Fibre Channel Logical Unit Page Byte PS (0) SPF (0) Page Code (18h) Page Length (06h) Reserved Protocol Identifier (0) Reserved...
Page 64: Sas Logical Unit Page (Hp Bridged)
Mode Select (6) SAS Logical Unit Page (HP Bridged) TABLE 4-29 shows the format of the Serial Attached SCSI (SAS) Logical Unit page. TABLE 4-29 SAS Logical Unit Page Byte PS (0) SPF (0) Page Code (18h) Page Length (06h) Reserved Protocol Identifier (6h) (MSB)
Page 65: Fibre Channel Port Control Page (Hp Bridged)
Mode Select (6) Fibre Channel Port Control Page (HP Bridged) TABLE 4-30 shows the format of the Fibre Channel Port Control page. TABLE 4-30 Fibre Channel Port Control Page Byte PS (0) SPF (0) Page Code (19h) Page Length (06h) Reserved Protocol Identifier (0) DTFD...
Page 66 Mode Select (6) DDIS Disable Discovery. If the library is not attached to an arbitrated loop, it shall ignore the DDIS bit. 0 = The target shall wait to complete target discovery as defined by FC-PLDA, FC-FLA, and FC-TAPE before allowing processing of tasks to resume.
Page 67 Mode Select (6) DTOLI Disable Target Originated Loop Initialization. If the library is not attached to an arbitrated loop, it shall ignore the DTOLI bit. 0 = The target attached by an arbitrated loop shall generate LIP(F7,xx) after it enables a port into a loop. 1 = The target attached by an arbitrated loop shall not generate a LIP following insertion into the loop.
Page 68: Sas Port Control Page (Hp Bridged)
Mode Select (6) SAS Port Control Page (HP Bridged) TABLE 4-31 shows the format of the Serial Attached SCSI (SAS) Port Control page. TABLE 4-31 SAS Port Control Page Byte PS (0) SPF (0) Page Code (19h) Page Length (0Eh) RSVD Continue Protocol Identifier (6h)
Page 69 Mode Select (6) Serial Attached SCSI Port Control Page Definitions: The parameters Saveable bit is set to 0. The library returns a value of: 0 = SubPage Format bit, indicating page_0 format is being used. Page Code This field is set to: 19h that identifies the page as the SAS Port Control mode page Protocol Identifier This field is set to:...
Page 70: Sas Phy Control And Discover Mode Subpage (Hp Bridged)
Mode Select (6) SAS Phy Control and Discover Mode Subpage (HP Bridged) TABLE 4-32 shows the format of the Serial Attached SCSI Phy Control and Discover Mode Subpage. TABLE 4-32 SAS Phy Control and Discover Mode Subpage Byte PS (0) SPF (1) Page Code (19h) Subpage Code (01h)
Page 71: Table 4-33 Sas Phy Mode Descriptor Data
Mode Select (6) SAS Phy Mode Descriptor Data TABLE 4-33 SAS Phy Mode Descriptor Data Byte Reserved (00h) Phy Identifier Reserved (00h) Reserved (00h) RSVD Attached Device Type Reserved (0) Reserved Negotiated Physical Link Rate Attach Attach Attach Reserved RSVD Init Port Init Port Init Port...
Page 72 Mode Select (6) Negotiated Physical This field indicates the logical link rate being used by the Phy: Link Rate 0h = UNKNOWN. Phy is enabled. Unknown Physical link rate. 1h = DISABLED. Phy is disabled. 2h = PHY_RESET_PROBLEM 3h = SPINUP_HOLD 4h = PORT_SELECTOR 8h = G1.
Page 73: Informational Exceptions Tapealert Page
Mode Select (6) Informational Exceptions TapeAlert Page TABLE 4-34 defines the Informational Exceptions TapeAlerts page. TABLE 4-34 Informational Exceptions TapeAlerts Page Byte PS (0) SPF (0) Page Code (1Ch) Page Length (0Ah) Perf (0) Rsvd (0) EBF(0) EWasc DExcpt (1) Test Rsvd (0) LogErr (0)
Page 74 Mode Select (6) Test Modes Two test mode options are supported in the current TapeAlert implementation. Test Mode for All Bits Supported Using the mode select command to initiate this test will set all of the flags supported by the TapeAlert implementation in the TapeAlert log page. The TapeAlert log sense page then can be read to give the host a snapshot of the supported flags.
Page 75: Element Address Assignment Mode Page
Mode Select (6) Element Address Assignment Mode Page Note – The library does not support changing Element Addresses. A check condition will be returned if the SCSI host issues a Mode Select command and attempts to change parameters in this page. TABLE 4-35 defines the Element Address Assignment Mode page.
Page 76 Mode Select (6) Mode Select (6) Element Address Assignment Mode Page Definitions: The Parameters Saveable bit is set to 0. Page Code Identifies the Element Address Assignment mode page. Parameter Length Indicates the length of the element address assignment parameter list. This field must be 12h, which indicates that there are an additional 12h (18d) bytes of parameter data following this byte.
Page 77 Mode Select (6) Element Address Assignments An initiator can modify the element addresses in the library using a Mode Select command. The four element types are: • Medium transport (the hand) • Storage element (storage cells) • Import/export (mailslot cells) •...
Page 78: Mode Select (10)
Mode Select (10) Mode Select (10) The 10-byte Mode Select command (55h) enables an initiator to specify certain operating parameters for the library. The library uses the saved or default versions of these parameters to configure itself during power-on or after a logical unit reset. The mode values sent to the library apply to all initiators.
Page 79 Mode Select (10) Parameter List Length The parameter list length field specifies the length in bytes of the mode parameter list that shall be contained in the data out sent by the host. The parameter list length is the sum of the length of the mode page header and one or more mode pages.
Page 80: Mode Select (10) Data
Mode Select (10) Mode Select (10) Data The initiator must provide mode parameter data in a parameter list including: “Mode Select Parameter Header” on page 80 “Fibre Channel Disconnect/Reconnect Page (HP Bridged)” on page 81 “SAS Disconnect/Reconnect Page (HP Bridged)” on page 83 “Fibre Channel Logical Unit Page (HP Bridged)”...
Page 81: Fibre Channel Disconnect/Reconnect Page (Hp Bridged)
Mode Select (10) Fibre Channel Disconnect/Reconnect Page (HP Bridged) TABLE 4-38 shows the format of the Mode Sense Fibre Channel Disconnect/ Reconnect page. TABLE 4-38 Fibre Channel Disconnect/reconnect Page Byte Page Code (02h) Page length (0Eh) Buffer Full Ratio Buffer Empty Ratio 4 to 5 (MSB) Bus Inactivity Limit...
Page 82 Mode Select (10) Disconnect Time Limit This field indicates the minimum delay between interconnect tenancies measured in increments of 128 transmission words. The value 0000h indicates that the disconnect time limit does not apply. Connect Time Limit The field indicates the maximum duration of a single interconnect tenancy, measured in increments of 128 transmission words.
Page 83: Sas Disconnect/Reconnect Page (Hp Bridged)
Mode Select (10) SAS Disconnect/Reconnect Page (HP Bridged) TABLE 4-39 shows the format of the Mode Sense Serial Attached SCSI Disconnect/ Reconnect page. TABLE 4-39 SAS Disconnect/Reconnect Page Byte Page Code (02h) Page Length (0Eh) Reserved (00h) Reserved (00h) (MSB) Bus Inactivity Time Limit (LSB) Reserved (00h)
Page 84 Mode Select (10) Maximum Burst Size For read data, this field contains the maximum amount of data in 512-byte increments that is transferred during a connection by an SSP target port per I_T_L_Q nexus without transferring at least one frame for a different I_T_L_Q nexus.
Page 85: Fibre Channel Logical Unit Page (Hp Bridged)
Mode Select (10) Fibre Channel Logical Unit Page (HP Bridged) TABLE 4-40 shows the format of the Fibre Channel Logical Unit page. TABLE 4-40 Fibre Channel Logical Unit Page Byte PS (0) SPF (0) Page Code (18h) Page Length (06h) Reserved Protocol Identifier (0) Reserved...
Page 86: Sas Logical Unit Page (Hp Bridged)
Mode Select (10) SAS Logical Unit Page (HP Bridged) TABLE 4-41 shows the format of the Serial Attached SCSI (SAS) Logical Unit page. TABLE 4-41 SAS Logical Unit Page Byte PS (0) SPF (0) Page Code (18h) Page Length (06h) Reserved Protocol Identifier (6h) (MSB)
Page 87: Fibre Channel Port Control Page (Hp Bridged)
Mode Select (10) Fibre Channel Port Control Page (HP Bridged) TABLE 4-42 shows the format of the Fibre Channel Port Control page. TABLE 4-42 Fibre Channel Port Control Page Byte PS (0) SPF (0) Page Code (19h) Page Length (06h) Reserved Protocol Identifier (0) DTFD...
Page 88 Mode Select (10) DDIS Disable Discovery. If the library is not attached to an arbitrated loop, it shall ignore the DDIS bit. 0 = The target shall wait to complete target discovery as defined by FC-PLDA, FC-FLA, and FC-TAPE before allowing processing of tasks to resume.
Page 89 Mode Select (10) DTOLI Disable Target Originated Loop Initialization. If the library is not attached to an arbitrated loop, it shall ignore the DTOLI bit. 0 = The target attached by an arbitrated loop shall generate LIP(F7,xx) after it enables a port into a loop. 1 = The target attached by an arbitrated loop shall not generate a LIP following insertion into the loop.
Page 90: Sas Port Control Page (Hp Bridged)
Mode Select (10) SAS Port Control Page (HP Bridged) TABLE 4-43 shows the format of the Serial Attached SCSI (SAS) Port Control page. TABLE 4-43 SAS Port Control Page Byte PS (0) SPF (0) Page Code (19h) Page Length (0Eh) RSVD Continue Protocol Identifier (6h)
Page 91 Mode Select (10) I_T Nexus Loss Time This field contains the minimum time that the SSP Target Port shall retry connection requests to an SSP initiator port that are rejected with responses indicating the SSP initiator port may no longer be present before recognizing an I_T nexus loss: 0000h = Vendor-specific amount of time.
Page 92: Sas Phy Control And Discover Mode Subpage (Hp Bridged)
Mode Select (10) SAS Phy Control and Discover Mode Subpage (HP Bridged) TABLE 4-44 shows the format of the Serial Attached SCSI Phy Control and Discover Mode Subpage. TABLE 4-44 SAS Phy Control and Discover Mode Subpage Byte PS (0) SPF (1) Page Code (19h) Subpage Code (01h)
Page 93: Table 4-45 Sas Phy Mode Descriptor Data
Mode Select (10) SAS Phy Mode Descriptor Data TABLE 4-45 SAS Phy Mode Descriptor Data Byte Reserved (00h) Phy Identifier Reserved (00h) Reserved (00h) RSVD Attached Device Type Reserved (0) Reserved Negotiated Physical Link Rate Attach Attach Attach Reserved RSVD Init Port Init Port Init Port...
Page 94 Mode Select (10) Attached Device Type This field indicates the device type attached to this Phy: 000b = No device attached 001b = SAS device 010b = Expander device 011b = Expander device compliant with a previous version of the SAS standard This field indicates the logical link rate being used by the Phy: Negotiated Physical Link Rate...
Page 95: Informational Exceptions Tapealert Page
Mode Select (10) Informational Exceptions TapeAlert Page TABLE 4-46 defines the Informational Exceptions TapeAlert page. TABLE 4-46 Informational Exceptions TapeAlert Page Byte PS (0) SPF (0) Page Code (1Ch) Page Length (0Ah) Perf (0) Rsvd (0) EBF (0) EWasc DExcpt (1) Test Rsvd (0) LogErr (0)
Page 96 Mode Select (10) Test Modes Two test mode options are supported in the current TapeAlert implementation. Test Mode for All Bits Supported Using the mode select command to initiate this test will set all of the flags supported by the TapeAlert implementation in the TapeAlert log page. The TapeAlert log sense page then can be read to give the host a snapshot of the supported flags.
Page 97: Element Address Assignment Mode Page
Mode Select (10) Element Address Assignment Mode Page Note – The library does not support changing Element Addresses. A check condition will be returned if the SCSI host issues a Mode Select command and attempts to change parameters in this page. TABLE 4-47 defines the Element Address Assignment Mode page.
Page 98 Mode Select (10) Mode Select (10) Element Address Assignment Mode Page Definitions: The Parameters Saveable bit is set to 0. Page Code Identifies the Element Address Assignment mode page. Parameter Length Indicates the length of the element address assignment parameter list. This field must be 12h, which indicates that there are an additional 12h (18d) bytes of parameter data following this byte.
Page 99 Mode Select (10) Element Address Assignments An initiator can modify the element addresses in the library using a Mode Select command. The four element types are: • Medium transport (the hand): • Storage element (storage cells) • Import/export (mailslot cells) •...
Page 100: Mode Sense (6)
Mode Sense (6) Mode Sense (6) The 6-byte Mode Sense command (1Ah) enables the library to report its operating mode parameters to the initiator. • The initiator can request one page or all pages of the mode parameters. • The initiator can use the Mode Select command to change the values of certain mode parameters.
Page 101 Mode Sense (6) Page Control 2h (10b) = Default Values: (continued) The library returns the default values. Requested pages are returned with each supported parameter set to its default. Parameters not supported by the library are set to 0. Default values for the Element Address Assignment page are based on the configuration of the library.
Page 102 Mode Sense (6) Allocation Length The allocation length field specifies the maximum number of bytes that the initiator has allocated for data returned from the Mode Sense command. The library transfers either the number of bytes specified by the allocation lengh field or all of the available mode sense data, whichever is less.
Page 103: Mode Sense (6) Data
Mode Sense (6) Mode Sense (6) Data The library returns the following mode sense data: • A four-byte Mode Parameter Header • One mode page or all mode pages in the order specified in the Page Code list Mode pages available include: “Fibre Channel Disconnect/Reconnect Page (HP Bridged)”...
Page 104: Mode Sense (6) Parameter Header Definition
Mode Sense (6) Mode Sense (6) Parameter Header Definition TABLE 4-49 shows the Mode Sense Parameter Header page. TABLE 4-49 Mode Sense (6) Parameter Header Byte Mode Data Length Reserved Reserved Block Descriptor Length (00h) Mode Sense (6) Parameter Header Page Definitions: Mode Data Length This field indicates the number of bytes of parameter information available to be transferred to the initiator, regardless of the allocation length.
Page 105: Fibre Channel Disconnect/Reconnect Page (Hp Bridged)
Mode Sense (6) Fibre Channel Disconnect/Reconnect Page (HP Bridged) TABLE 4-50 shows the format of the Mode Sense Fibre Channel Disconnect/ Reconnect page. TABLE 4-50 Fibre Channel Disconnect/Reconnect Page Byte Page Code (02h) Page length (0Eh) Buffer Full Ratio Buffer Empty Ratio 4 to 5 (MSB) Bus Inactivity Time Limit...
Page 106 Mode Sense (6) Connect Time Limit The field indicates the maximum duration of a single interconnect tenancy, measured in increments of 128 transmission words. 0000h indicates that there is no connect time limit. Maximum Burst Size This field indicates the maximum size of FCP_DATA IU that the device server shall transfer to the initiator or request from the initiator.
Page 107: Sas Disconnect/Reconnect Page (Hp Bridged)
Mode Sense (6) SAS Disconnect/Reconnect Page (HP Bridged) TABLE 4-51 shows the format of the Mode Sense SAS Disconnect/Reconnect page. TABLE 4-51 SAS Disconnect/Reconnect Page Byte Page Code (02h) Page Length (0Eh) Reserved (00h) Reserved (00h) (MSB) Bus Inactivity Time Limit (LSB) Reserved (00h) Reserved (00h)
Page 108 Mode Sense (6) Maximum Burst Size For read data, this field contains the maximum amount of data in 512-byte increments that is transferred during a connection by an SSP target port per I_T_L_Q nexus without transferring at least one frame for a different I_T_L_Q nexus.
Page 109: Fibre Channel Logical Unit Page (Hp Bridged)
Mode Sense (6) Fibre Channel Logical Unit Page (HP Bridged) TABLE 4-52 shows the format of the Fibre Channel Logical Unit page. TABLE 4-52 Fibre Channel Logical Unit Page Byte PS (0) SPF (0) Page Code (18h) Page Length (06h) Reserved Protocol Identifier (0) Reserved...
Page 110: Sas Logical Unit Page (Hp Bridged)
Mode Sense (6) SAS Logical Unit Page (HP Bridged) TABLE 4-53 shows the format of the SAS Logical Unit Page. TABLE 4-53 SAS Logical Unit Page Byte PS (0) SPF (0) Page Code (18h) Page Length (06h) Reserved Protocol Identifier (6h) (MSB) Reserved (LSB)
Page 111: Fibre Channel Port Control Page (Hp Bridged)
Mode Sense (6) Fibre Channel Port Control Page (HP Bridged) TABLE 4-54 shows the format of the Fibre Channel Port Control page. TABLE 4-54 Fibre Channel Port Control Page Byte PS (0) SPF (0) Page Code (19h) Page Length (06h) Reserved Protocol Identifier (0) DTFD...
Page 112 Mode Sense (6) Fibre Channel Port Control Page Definitions: The Parameters Saveable bit is set to 0. The library returns a value of: 0 = SubPage Format bit, indicating page_0 format is being used. Protocol Identifier This field is set to: 0h that indicates the Fibre Channel protocol.
Page 113 Mode Sense (6) Require Hard Address. If the library is not attached to an arbitrated loop, it shall ignore the RHA bit. 0 = The target follows the normal initialization procedure, including the possibility of obtaining a soft address during the loop initialization process. 1 = The target attached to an arbitrated loop shall only attempt to obtain its hard address.
Page 114: Sas Port Control Page (Hp Bridged)
Mode Sense (6) SAS Port Control Page (HP Bridged) TABLE 4-55 shows the format of the SAS Port Control page. TABLE 4-55 SAS Port Control Page Byte PS (0) SPF (0) Page Code (19h) Page Length (0Eh) RSVD Continue Protocol Identifier (6h) Reserved (MSB) I_T Nexus Loss Time...
Page 115 Mode Sense (6) Broadcast Asynchronous The device server shall: Event 0 = Disable origination of Broadcast (Asynchronous Event). 1 = Enable origination of Broadcast (Asynchronous Event). The Ready LED Meaning bit specifies the READY LED signal behavior. Ready LED Meaning I_T Nexus Loss Time This field contains the minimum time that the SSP Target Port shall retry connection requests to an SSP initiator port that are rejected with responses...
Page 116: Sas Phy Control And Discover Mode Subpage (Hp Bridged)
Mode Sense (6) SAS Phy Control and Discover Mode Subpage (HP Bridged) TABLE 4-56 shows the format of the Serial Attached SCSI Phy Control and Discover Mode Subpage. TABLE 4-56 SAS Phy Control and Discover Mode Subpage Byte PS (0) SPF (1) Page Code (19h) Subpage Code (01h)
Page 117: Table 4-57 Sas Phy Mode Descriptor Data
Mode Sense (6) SAS Phy Mode Descriptor Data TABLE 4-57 SAS Phy Mode Descriptor Data Byte Reserved (00h) Phy Identifier Reserved (00h) Reserved (00h) RSVD Attached Device Type Reserved (0) Reserved Negotiated Physical Link Rate Attach Attach Attach Reserved RSVD Init Port Init Port Init Port...
Page 118 Mode Sense (6) Negotiated Physical This field indicates the logical link rate being used by the Phy: Link Rate 0h = UNKNOWN. Phy is enabled. Unknown Physical Link Rate. 1h = DISABLED. Phy is disabled. 2h = PHY_RESET_PROBLEM 3h = SPINUP_HOLD 4h = PORT_SELECTOR 8h = G1.
Page 119: Sas Shared Control Mode Subpage (Hp Bridged)
Mode Sense (6) SAS Shared Control Mode Subpage (HP Bridged) TABLE 4-58 shows the format of the SAS Shared Control Mode Subpage. TABLE 4-58 SAS Shared Control Mode Subpage Byte PS (0) SPF (1) Page Code (19h) Sub-Page Code (02h) 2 to 3 Page Length (0Ch) Reserved (00h)
Page 120: Sas Enhanced Phy Control Subpage (Hp Bridged)
Mode Sense (6) SAS Enhanced Phy Control Subpage (HP Bridged) TABLE 4-59 shows the format of the Serial Attached SCSI Enhanced Phy Control Mode Subpage. TABLE 4-59 SAS Enhanced Phy Control Mode Subpage Byte PS (0) SPF (1) Page Code (19h) Sub-Page Code (03h) 2 to 3 Page Length (2Ch)
Page 121 Mode Sense (6) Enhanced Phy Control Mode Descriptor Data TABLE 4-60 Enhanced Phy Control Mode Descriptor Data Byte Reserved (00h) Phy Identifier 2 to 3 (MSB) Descriptor Length (10h) (LSB) 4 to 7 (MSB) Programmed Phy Capabilities (LSB) 8 to 11 (MSB) Current Phy Capabilities (LSB)
Page 122 Mode Sense (6) Phy Capabilities Data TABLE 4-61 Phy Capabilities Data Byte Start (1B) TX SSC Reserved Requested Logical Link Rate Type Supported Settings Reserved Without With SSC Without With SSC Without With SSC Reserved (00h) Reserved Parity Phy Capabilities Data Definitions: TX SSC Type The value 0 indicates that the phy's transmitter uses down-spreading SSC when SSC is enabled (for example, the phy is a SAS phy), or that the phy does not...
Page 123 Mode Sense (6) Parity The Parity bit shall be set to one or zero such that the total number of SNW-3 Phy device capabilities bits that are set to one is even, including the Start bit and the Parity bit. Julyl 2017 Command Set 123...
Page 124: Informational Exceptions Tapealert Control Page
Mode Sense (6) Informational Exceptions TapeAlert Control Page TABLE 4-62 shows the format of the Mode Sense (6) Informational Exceptions TapeAlert Control page. TABLE 4-62 Informational Exceptions TapeAlert Control Page Byte PS (0) SPF (0) Page Code (1Ch) Page Length (0Ah) Perf Rsvd EWasc (0)
Page 125: Element Address Assignment Page
Mode Sense (6) Element Address Assignment Page TABLE 4-63 defines the Element Address Assignment page of the Mode Sense (6) command. TABLE 4-63 Mode Sense (6) Element Address Assignment Page Byte PS (0) Rsvd (0) Page Code (1Dh) Parameter Length (12h) (MSB) First Medium Transport Element Address (LSB)
Page 126 Mode Sense (6) Mode Sense (6) Element Address Assignment Page Definitions: The Parameters Saveable bit is set to 0. Page Code Identifies the Element Address Assignment mode page and returns a value of 1Dh. Parameter Length 12h = Indicates the amount of element address data following this byte. First Medium Transport 0000h = Identifies the address of the hand.
Page 127: Transport Geometry Mode Page
Mode Sense (6) Transport Geometry Mode Page This table defines the Mode Sense Transport Geometry Mode page. TABLE 4-64 Transport Geometry Mode Page Byte PS (0) Rsvd Page Code (1Eh) Parameter Length (02h) Reserved (0) Rotate (0) Member Number in Transport Element Set (00h) Transport Geometry Mode Page Definitions: The Parameters Saveable bit is set to 0.
Page 128: Device Capabilities Page
Mode Sense (6) Device Capabilities Page TABLE 4-65 defines the Device Capabilities page of the Mode Sense command. TABLE 4-65 Device Capabilities Page Byte PS (0) Rsvd (0) Page Code (1Fh) Parameter Length (12h) Reserved (0h) StorDT StorI/E StorST StorMT Reserved (0h) Reserved (0h) MT->DT...
Page 129 Mode Sense (6) Device Capabilities Page Definitions: Parameter Length This field indicates the amount of device capabilities data following this byte. The library returns a value of 12h (18d). StorDT This field identifies the ability of a tape drive to perform the function of element storage.
Page 130 Mode Sense (6) Device Capabilities Page Definitions: I/E -> ST This field identifies the support for the Move Medium command, where the source is a mailslot cell, and the destination is a cartridge tape storage cell. The library returns a value of 1. I/E ->...
Page 131 Mode Sense (6) Device Capabilities Page Definitions: ST < > MT This field identifies the support for the Exchange Medium command, where the source and destination 2 elements are a cartridge tape storage cell, and the destination 1 element is the hand. The library returns a value of 0.
Page 132: Mode Sense (10)
Mode Sense (10) Mode Sense (10) The 10-byte Mode Sense command (5Ah) enables the library to report its operating mode parameters to the initiator. TABLE 4-66 Mode Sense (10) Command Byte Operation Code (5Ah) Ignored LLBA (0) Reserved Page Control Page Code SubPage Code (MSB)
Page 133 Mode Sense (10) Page Control 2h (10b) = Default Values: The library returns the default values. Requested pages are returned with each supported parameter set to its default Parameters not supported by the library are set to 0. Default values for the Element Address Assignment page are based on the configuration of the library.
Page 134 Mode Sense (10) Allocation Length The allocation length field specifies the maximum number of bytes that the initiator has allocated for data returned from the Mode Sense command. The library transfers either the number of bytes specified by the allocation length field or all of the available mode sense data, whichever is less.
Page 135: Mode Sense (10) Data
Mode Sense (10) Mode Sense (10) Data The library returns the following mode sense data: • A eight-byte Mode Parameter Header followed by: • One mode page or all mode pages in the order specified in the Page Code list. •...
Page 136: Mode Sense (10) Parameter Header Definition
Mode Sense (10) Mode Sense (10) Parameter Header Definition TABLE 4-67 shows the Mode Sense Parameter Header page. TABLE 4-67 Mode Sense (10) Parameter Header Page Byte (MSB) Mode Data Length (LSB) Reserved Reserved Reserved Reserved (MSB) Block Descriptor Length (00h) (LSB) Mode Sense (10) Parameter Header Page Definitions: Mode Data Length...
Page 137: Fibre Channel Disconnect/Reconnect Page (Hp Bridged)
Mode Sense (10) Fibre Channel Disconnect/Reconnect Page (HP Bridged) TABLE 4-68 shows the format of the Mode Sense Fibre Channel Disconnect/ Reconnect page. TABLE 4-68 Fibre Channel Disconnect/Reconnect Page (HP Bridged) Byte Page Code (02h) Page length (0Eh) Buffer Full Ratio Buffer Empty Ratio 4 to 5 (MSB)
Page 138 Mode Sense (10) Mode Sense: Fibre Channel Disconnect/Reconnect Page Definitions The parameters Saveable bit is set to 0. The library returns a value of 0 = the SubPage Format bit, indicating page_0 format is being used. Page Code This field is set to: 02h = identifies the page as the Disconnect/Reconnect page.
Page 139: Sas Disconnect/Reconnect Page (Hp Bridged)
Mode Sense (10) SAS Disconnect/Reconnect Page (HP Bridged) TABLE 4-69 shows the format of the Mode Sense Serial Attached SCSI Disconnect/ Reconnect page. TABLE 4-69 SAS Disconnect/Reconnect Page (HP Bridged) Byte Page Code (02h) Page Length (0Eh) Reserved (00h) Reserved (00h) (MSB) Bus Inactivity Time Limit (LSB)
Page 140 Mode Sense (10) Mode Sense: SAS Disconnect/Reconnect Page Definitions: The parameters Saveable bit is set to 0. The library returns a value of: 0 = SubPage Format bit, indicating page_0 format is being used. Page Code This field is set to: 02h = identifies the page as the Disconnect/Reconnect page.
Page 141: Fibre Channel Logical Unit Page (Hp Bridged)
Mode Sense (10) Fibre Channel Logical Unit Page (HP Bridged) TABLE 4-70 shows the format of the Fibre Channel Logical Unit page. TABLE 4-70 Fibre Channel Logical Unit Page Byte PS (0) SPF (0) Page Code (18h) Page Length (06h) Reserved Protocol Identifier (0) Reserved...
Page 142: Sas Logical Unit Page (Hp Bridged)
Mode Sense (10) SAS Logical Unit Page (HP Bridged) TABLE 4-71 shows the format of the Serial Attached SCSI (SAS) Logical Unit Page. TABLE 4-71 SAS Logical Unit Page Byte PS (0) SPF (0) Page Code (18h) Page Length (06h) Reserved Protocol Identifier (6h) (MSB)
Page 143: Fibre Channel Port Control Page (Hp Bridged)
Mode Sense (10) Fibre Channel Port Control Page (HP Bridged) TABLE 4-72 shows the format of the Fibre Channel Port Control page. TABLE 4-72 Fibre Channel Port Control Page Byte PS (0) SPF (0) Page Code (19h) Page Length (06h) Reserved Protocol Identifier (0) DTFD...
Page 144 Mode Sense (10) DDIS Disable Discovery. If the library is not attached to an arbitrated loop, it shall ignore the DDIS bit. 0 = The target shall wait to complete target discovery as defined by FC-PLDA, FC-FLA, and FC-TAPE before allowing processing of tasks to resume.
Page 145 Mode Sense (10) DTOLI Disable Target Originated Loop Initialization. If the library is not attached to an arbitrated loop, it shall ignore the DTOLI bit. 0 = The target attached by an arbitrated loop shall generate LIP(F7,xx) after it enables a port into a loop. 1 = The target attached by an arbitrated loop shall not generate a LIP following insertion into the loop.
Page 146: Sas Port Control Page (Hp Bridged)
Mode Sense (10) SAS Port Control Page (HP Bridged) TABLE 4-73 shows the format of the Serial Attached SCSI (SAS) Port Control page. TABLE 4-73 SAS Port Control Page Byte PS (0) SPF (0) Page Code (19h) Page Length (0Eh) RSVD Continue Protocol Identifier (6h)
Page 147 Mode Sense (10) I_T Nexus Loss Time This field contains the minimum time that the SSP Target Port shall retry connection requests to an SSP initiator port that are rejected with responses indicating the SSP initiator port may no longer be present before recognizing an I_T nexus loss: 0000h = Vendor-specific amount of time.
Page 148: Sas Phy Control And Discover Mode Subpage (Hp Bridged)
Mode Sense (10) SAS Phy Control and Discover Mode Subpage (HP Bridged) TABLE 4-74 shows the format of the Serial Attached SCSI (SAS) Phy Control and Discover Mode Subpage. TABLE 4-74 SAS Phy Control and Discover Mode Subpage Byte PS (0) SPF (1) Page Code (19h) Subpage Code (01h)
Page 149: Table 4-75 Sas Phy Mode Descriptor Data
Mode Sense (10) SAS Phy Mode Descriptor Data TABLE 4-75 SAS Phy Mode Descriptor Data Byte Reserved (00h) Phy Identifier Reserved (00h) Reserved (00h) RSVD Attached Device Type Reserved (0) Reserved Negotiated Physical Link Rate Attach Attach Attach Reserved RSVD Init Port Init Port Init Port...
Page 150 Mode Sense (10) Attached Device Type This field indicates the device type attached to this Phy: 000b = No device attached 001b = SAS device 010b = Expander device 011b = Expander device compliant with a previous version of the SAS standard Negotiated Physical This field indicates the logical link rate being used by the Phy:...
Page 151: Sas Shared Port Control Mode Subpage (Hp Bridged)
Mode Sense (10) SAS Shared Port Control Mode Subpage (HP Bridged) TABLE 4-76 shows the format of the Serial Attached SCSI Shared Port Control Mode Subpage. TABLE 4-76 SAS Shared Port Control Subpage Byte PS (0) SPF (1) Page Code (19h) Sub-Page Code (02h) 2 to 3 Page Length (0Ch)
Page 152: Sas Enhanced Phy Control Subpage (Hp Bridged)
Mode Sense (10) SAS Enhanced Phy Control Subpage (HP Bridged) TABLE 4-77 shows the format of the Serial Attached SCSI Enhanced Phy Control Mode Subpage. TABLE 4-77 SAS Enhanced Phy Control Mode Subpage Byte PS (0) SPF (1) Page Code (19h) Sub-Page Code (03h) 2 to 3 Page Length (2Ch)
Page 153: Table 4-78 Enhanced Phy Control Mode Descriptor Data
Mode Sense (10) Enhanced Phy Control Mode Descriptor Data TABLE 4-78 Enhanced Phy Control Mode Descriptor Data Byte Reserved (00h) Phy Identifier 2 to 3 (MSB) Descriptor Length (10h) (LSB) 4 to 7 (MSB) Programmed Phy Capabilities (LSB) 8 to 11 (MSB) Current Phy Capabilities (LSB)
Page 154: Table 4-79 Phy Capabilities Data
Mode Sense (10) Phy Capabilities Data TABLE 4-79 Phy Capabilities Data Byte Start (1B) TX SSC Reserved Requested Logical Link Rate Type Supported Settings Reserved Without With SSC Without With SSC Without With SSC Reserved (00h) Reserved Parity Phy Capabilities Data Definitions: TX SSC Type The value 0 indicates that the phy's transmitter uses down-spreading SSC when SSC is enabled (for example, the phy is a SAS phy), or that the phy does...
Page 155: Informational Exceptions Tapealert Control Page
Mode Sense (10) Informational Exceptions TapeAlert Control Page TABLE 4-80 shows the format of the Mode Sense (10) Informational Exceptions TapeAlert Control page. TABLE 4-80 Informational Exceptions TapeAlert Control Page Byte PS (0) SPF (0) Page Code (1Ch) Page Length (0Ah) Perf (0) Rsvd (0) EBF (0)
Page 156: Element Address Assignment Page
Mode Sense (10) Element Address Assignment Page TABLE 4-81 defines the Element Address Assignment page of the Mode Sense (10) command. TABLE 4-81 Element Address Assignment Page Byte PS (0) Rsvd (0) Page Code (1Dh) Parameter Length (12h) (MSB) First Medium Transport Element Address (LSB) (0000h) (MSB)
Page 157 Mode Sense (10) Element Address Assignment Page Definitions: The Parameters Saveable bit is set to 0. Page Code Identifies the Element Address Assignment mode page and returns a value of 1Dh. Parameter Length 12h = Indicates the amount of element address data following this byte. First Medium Transport 0000h = Identifies the address of the hand.
Page 158: Transport Geometry Mode Page
Mode Sense (10) Transport Geometry Mode Page TABLE 4-82 defines the Mode Sense Transport Geometry Mode page. TABLE 4-82 Transport Geometry Mode Page Byte PS (0) Rsvd (0) Page Code (1Eh) Parameter Length (02h) Reserved (0) Rotate (0) Member Number in Transport Element Set (00h) Transport Geometry Mode Page Definitions: The Parameters Saveable bit is set to 0.
Page 159: Device Capabilities Page
Mode Sense (10) Device Capabilities Page TABLE 4-83 defines the Device Capabilities page of the Mode Sense (10) command. TABLE 4-83 Device Capabilities Page Byte PS (0) Rsvd (0) Page Code (1Fh) Parameter Length (12h) Reserved (0h) StorDT StorI/E StorST StorMT Reserved (0h) Reserved (0h)
Page 160 Mode Sense (10) Device Capabilities Page Definitions: The Parameters Saveable bit is set to 0. Page Code The Page Code field identifies the Device Capabilities mode page and always contains a value of 1Fh. Parameter Length This field indicates the amount of device capabilities data following this byte. The library returns a value of 12h (18d).
Page 161 Mode Sense (10) I/E -> I/E This field identifies the support for the Move Medium command, where both the source, and the destination is a mailslot cell. The library returns a value of 1. I/E -> ST This field identifies the support for the Move Medium command, where the source is a mailslot cell, and the destination is a cartridge tape storage cell.
Page 162 Mode Sense (10) ST < > MT This field identifies the support for the Exchange Medium command, where the source and destination 2 elements are a cartridge tape storage cell, and the destination 1 element is the hand. The library returns a value of 0. I/E <...
Page 163: Move Medium
Move Medium Move Medium The Move Medium command (A5h) moves a cartridge tape from one specific element location to another specific element location. The Mode Sense command provides a matrix with the valid source and destination element combinations for the Move Medium command. When the destination element is a tape drive, the library performs the move motion, and waits until the tape drive load operation completes before returning status for the move command.
Page 164 Move Medium Move Option These two bits define optional operations associated with the Move Medium command. 00 = The library performs a normal move medium operation. If the source element is a data transfer element and there is a cartridge in the data transfer element, the library unloads the cartridge in the data transfer element and then performs the move operation.
Page 165: Persistent Reserve In
Persistent Reserve In Persistent Reserve In The Persistent Reserve In (5Eh) and Persistent Reserve Out (5Fh) commands resolve contention among multiple initiators and multiple-port targets within the system. The Persistent Reserve In command is used by initiators to obtain information about active registrations or an active reservation.
Page 166: Read Keys Data
Persistent Reserve In Read Keys Data The Read Keys service action requests that the library returns a list of all the current Reservation keys it has registered. TABLE 4-86 shows the format of the parameter data returned in response to a Persistent Reserve In command with the Read Keys service action.
Page 167: Read Reservations Data
Persistent Reserve In Read Reservations Data The Read Reservations service action requests that the library return a description of all current Reservation keys it has registered. TABLE 4-87 for the format of the parameter data returned in response to a Persistent Reserve In command with the Read Reservations service action.
Page 168 Persistent Reserve In TABLE 4-88 Reservation Descriptors Format Byte (MSB) Reservation Key (LSB) (MSB) Obsolete (LSB) Reserved (00h) Scope Type Obsolete (00h) Reservation Descriptors Format Definitions: Reservation Key This value indicates the reservation key for the descriptor data that follows. Scope The value in the Scope field indicates whether a persistent reservation applies to an entire logical unit or to an element.
Page 169: Report Capabilities Data
Persistent Reserve In Report Capabilities Data The format for the parameter data provided in response to a Persistent Reserve In command with the Report Capabilities service action is shown in TABLE 4-89. TABLE 4-89 Report Capabilities Data Byte (MSB) Length (0008h) (LSB) Reserved SIP_C...
Page 170 Persistent Reserve In Type Mask Valid bit 0 = The PERSISTENT RESERVATION TYPE MASK field shall be ignored 1 = The PERSISTENT RESERVATION TYPE MASK field contains a bit map indicating which persistent reservation types are supported by the library. PTPL_A Persist Through Power Loss Activated bit 0 = The persist through power loss capability is not activated.
Page 171: Read Full Status Data
Persistent Reserve In Read Full Status Data The Read Full Status service action requests that the library return a list of all the current Reservation keys it has registered along with information about each initiator. TABLE 4-91 shows the format of the parameter data returned in response to a Persistent Reserve In command with the Read Full Status service action.
Page 172 Persistent Reserve In TABLE 4-92 Read Full Status Descriptor Data Byte (MSB) Reservation Key (LSB) (MSB) Reserved (LSB) Reserved ALL_TG_ R_HOLD Scope Type (MSB) Reserved (LSB) (MSB) Relative Target Port Identifier (LSB) (MSB) Additional Descriptor Length (18h) (LSB) (MSB) Transport ID Data (LSB) Read Full Status Descriptor Data Definitions: Reservation Key...
Page 173: Table 4-92 Read Full Status Descriptor Data
Persistent Reserve In Read Full Status Descriptor Data Definitions: Type When the Reservation Holder Bit is 1, this field indicates the type of Persistent Reservation: 3h = Exclusive Access 6h = Exclusive Access - Registrants Only 8h = Exclusive Access - All Registrants Relative Target Port 1 = Target Port 1 Identifier...
Page 174 Persistent Reserve In TABLE 4-94 SAS Transport ID Data Byte Format Code (00b) Reserved Protocol Identifier (6h) 1 - 3 Reserved 4 - 11 SAS Address 12 - 23 Reserved SAS Transport ID Data Definitions: Protocol Identifier This field is set to 6h indicating the Serial Attached SCSI protocol SAS Address This field specifies the SAS Address of the Initiator Port.
Page 175: Persistent Reserve Out
Persistent Reserve Out Persistent Reserve Out The Persistent Reserve Out (5Fh) command reserves a target for the exclusive or shared use of an initiator. TABLE 4-95 Persistent Reserve Out Command Byte Operation Code (5Fh) Ignored Service Action Scope Type Reserved (00h) Reserved (00h) (MSB) Parameter List Length...
Page 176 Persistent Reserve Out Persistent Reserve Out Command Definitions: Service Action This value indicates the action that will result from the Persistent Reservation Command: 00h = Register: Register or Unregister a reservation key with the library without generating a reservation. 01h = Reserve: Create a persistent reservation of the scope and type specified in Byte 2.
Page 177 Persistent Reserve Out The parameter list for the Persistent Reserve Out command has this format: TABLE 4-96 Persistent Reserve Out Parameter List Byte (MSB) Reservation Key (LSB) (MSB) Service Action Reservation Key (LSB) (MSB) Obsolete (LSB) Rsvd (0) Reserved (0h) SPEC-I- ALL- APTPL...
Page 178: Table 4-97 Persistent Reserve Out Service Actions And Valid Parameters
Persistent Reserve Out TABLE 4-97 summarizes which fields are set by the application client and interpreted by the library for each service action and scope value. TABLE 4-97 Persistent Reserve Out Service Actions and Valid Parameters Service Action Service Allowed Reservation Reservation Action...
Page 179: Position To Element
Position to Element Position to Element The Position to Element command (2Bh) is supported only for compatibility with existing applications. It causes the hand to be positioned to the specified destination element address. TABLE 4-99 Position to Element Command Byte Operation Code (2Bh) Ignored Reserved (00h)
Page 180: Prevent/Allow Medium Removal
Prevent/Allow Medium Removal Prevent/Allow Medium Removal The Prevent/Allow Medium Removal command (1Eh) requests that the library enable or disable operator access to the mailslot and magazine(s). • If allowed, the mailslot and magazine(s) are unlocked. The mailslot may be opened and the magazine(s) may be unlatched from the user interface. •...
Page 181: Read Element Status
Read Element Status Read Element Status The Read Element Status command (B8h) requests that the library return the status of the elements in the library. TABLE 4-101 Read Element Status Command Byte Operation Code (B8h) Ignored VolTag Element Type Code (MSB) Starting Element Address (LSB)
Page 182 Read Element Status Starting Element Address This field specifies the minimum element address to report. Only elements with an element address greater than or equal to the Starting Element Address are reported. Element descriptor blocks are not generated for undefined element addresses.
Page 183: Read Element Status Data
Read Element Status Read Element Status Data The library returns data for a Read Element Status command with this structure: • An eight-byte Element Status Data header, followed by • One to four element pages, one page per element type. A page consists of: •...
Page 184: Element Status Page Header Definition
Read Element Status Element Status Page Header Definition The library sends this header once for each type of element descriptors. TABLE 4-103 Element Status Page Header Byte Reserved Element Type Code PVolTag AVolTag Reserved (0) (MSB) Element Descriptor Length (LSB) Reserved (00h) (MSB) Byte Count of Report Available (all pages, n-7)
Page 185 Read Element Status Byte Count of Descriptor This field indicates the total number of bytes of element descriptor data Data Available available for the elements of this element type that meet the requirements of the Read Element Status command. This count does not include the Element Status Page header bytes.
Page 186: Medium Transport Element Descriptor Definition
Read Element Status Medium Transport Element Descriptor Definition Medium transport elements are robotic components capable of physically moving cartridges. The Medium Transport Element Descriptor defines the robot characteristics. TABLE 4-104 Medium Transport Element Descriptor Byte (MSB) Element Address (LSB) Reserved (00h) Except Rsvd (0) Full...
Page 187 Read Element Status Medium Transport Element Descriptor Definitions: Element Address This field contains the element address of the robot. Except This bit indicates the current operational state of the robot: 0 = The hand is operational. 1 = The hand is in an abnormal state. The Additional Sense Code (ASC) and the Additional Sense Code Qualifier (ASCQ) fields contain information regarding the abnormal state.
Page 188 Read Element Status Primary Volume Tag When the PVolTag bit is set to 1, the library returns volume tag Information information. When PVolTag is set to 0, this field is omitted, and the reserved fields below it are moved up. The Primary Volume Tag field contains the formatted null-terminated ASCII barcode label on the tape cartridge.
Page 189 Read Element Status Primary Volume Tag • If the cartridge label is "KL10203040L6", this field will contain Information (continued) "L102030" and the domain and type fields will contain 'L' and '6'. • No type checking: This field contains all characters on the label without checking the media domain and type.
Page 190 Read Element Status Media Type The Media Type field along with the Media Domain field provides a hierarchy of information that indicates the type of media in the element. If the Media Domain field is 43h (43h is ‘C’), the value reported for the Media Type field identifies in ASCII the type of LTO cleaning cartridge: 1 = The element contains an HP Generation 1 LTO cleaning cartridge.
Page 191: Storage Element Descriptor Definition
Read Element Status Storage Element Descriptor Definition Storage elements are the main cartridge tape storage cells of the library. The Storage Element Descriptor describes a storage cell. TABLE 4-105 Storage Element Descriptor Byte (MSB) Element Address (LSB) Reserved (00h) Access (1) Except Rsvd (0) Full...
Page 192 Read Element Status Storage Element Descriptor Definitions: Element Address This field contains the element address of the storage element reported. Access This bit indicates access is allowed to the storage element by the hand. The library returns a value of 1. Except This bit indicates the operational state of the storage element: 0 = The storage element is in a normal state.
Page 193 Read Element Status Primary Volume Tag • Trim last two characters (default): This field contains the first 6 Information (continued) characters of the cartridge label. • If the cartridge label is "KL1020L6", this field will contain "KL1020" and the domain and type fields will contain 'L' and '6'. •...
Page 194 Read Element Status Identifier Type The Identifier Type field indicates the format and assignment authority for the identifier and is set to 0 (not supported) for the Storage Element Descriptor: 0h = Vendor Specific Identifier Length This field indicates the length of the Identifier field and is set to 0 (not supported) for the Storage Element Descriptor.
Page 195: Import/Export Element Descriptor Definitions
Read Element Status Import/Export Element Descriptor Definitions Import/Export elements are the mailslot of the library. The Import/Export Element Descriptor describes a mailslot cell. TABLE 4-106 Import/Export Element Descriptor Byte (MSB) Element Address (LSB) InEnab ExEnab Access Except ImpExp Full Reserved (00h) Additional Sense Code Additional Sense Code Qualifier Reserved (00h)
Page 196 Read Element Status Import/Export Element Descriptor Definitions: Element Address This field contains the element address of the import/export element reported. Operator Intervention Required bit 0 = No operator intervention required to make the mailslot accessible. 1 = Operator intervention required to make the mailslot accessible. This bit is set to zero to indicate the import/export element is a mailslot.
Page 197 Read Element Status Invert The library does not support multi-sided media. The information reported is 0. 0 = The element is enabled (for example a magazine or drive has been installed or has been logically enabled) 1 = The element is disabled This field provides the type of medium currently present in the element as Medium Type determined by the medium changer.
Page 198 Read Element Status Primary Volume Tag • Trim first two characters: This field contains the third through eighth Information (continued) characters on the label. • If the cartridge label is "KL1020L6", this field will contain "1020L6" and the domain and type fields will contain 'L' and '6'. •...
Page 199 Read Element Status Media Type The Media Type field along with the Media Domain field provides a hierarchy of information that indicates the type of media in the element. If the Media Domain field is 43h (43h is ‘C’), the value reported for the Media Type field identifies in ASCII the type of LTO cleaning cartridge: 1 = The element contains a HP Generation 1 LTO cleaning cartridge.
Page 200: Data Transfer Element Descriptor Definitions
Read Element Status Data Transfer Element Descriptor Definitions Data transfer elements are the tape drives in the library. The Data Transfer Element Descriptor Definitions page describes a tape drive. The following table shows the data returned when the DvcID bit in the command is set to 0. TABLE 4-107 Data Transfer Element Descriptor When DvcID = 0 Byte (MSB)
Page 201 Read Element Status Data Transfer Element Descriptor When DvcID = 0 Definitions: Element Address This field contains the element address of the data transfer element reported. Access This bit indicates access is allowed to the data transfer element by the hand: 0 = Access is not allowed to the tape drive element by the hand.
Page 202 Read Element Status Primary Volume Tag When the PVolTag bit is set to 1, the library returns volume tag Information information. When PVolTag is set to 0, this field is omitted, and the reserved fields below it are moved up. The Primary Volume Tag field contains the formatted null-terminated ASCII barcode label on the tape cartridge.
Page 203 Read Element Status Primary Volume Tag • No type checking: This field contains all characters on the label without Information (continued) checking the media domain and type. • If the cartridge label is "KL1020L6", this field will contain "KL1020L6" and the domain and type fields will contain FFh and FFh.
Page 204 Read Element Status Media Type (continued) If the Media Domain field is 4Ch (4Ch is ‘L’), the value reported for the Media Type field identifies in ASCII the type of LTO cartridge: 1 = The element contains a 100 GB Generation 1 LTO cartridge. 2 = The element contains a 200 GB Generation 2 LTO cartridge.
Page 205: Data Transfer Element Descriptor Definitions
Read Element Status Data Transfer Element Descriptor Definitions Data transfer elements are the tape drives in the library. The Data Transfer Element Descriptor Definitions page describes a tape drive. The following table shows the data returned when the DvcID bit in the command is set to 1. TABLE 4-108 Data Transfer Element Descriptor When DvcID = 1 Byte (MSB)
Page 206 Read Element Status Data Transfer Element Descriptor (DvcID = 1) Definitions: Element Address This field contains the element address of the data transfer element reported. Access This bit indicates access is allowed to the data transfer element by the hand: 0 = Access is not allowed to the tape drive element by the hand.
Page 207 Read Element Status Primary Volume Tag • Trim last two characters (default): This field contains the first 6 Information (continued) characters of the cartridge label. • If the cartridge label is "KL1020L6", this field will contain "KL1020" and the domain and type fields will contain 'L' and '6'. •...
Page 208 Read Element Status Identifier Type The Identifier Type field indicates the format and assignment authority for the identifier: 0h = No assignment authority was used, and consequently there is no guarantee that the identifier is globally unique. In other words, the identifier is vendor specific.
Page 209 Read Element Status Transport Type If the Transport Domain field is 4Ch (4Ch is ‘L’), the value in the Transport Type field indicates that the drive installed is: 3Bh = An HP Generation 5 LTO drive. 3Dh = An HP Generation 6 LTO drive. 3Eh = An IBM Generation 6 LTO drive.
Page 210: Release (6)
Release (6) Release (6) The 6-byte Release command (17h) enables the initiator to release a unit reservations of the library as set using a previous Reserve command. Performing a unit release of a library that has no active reservations is not considered an error.
Page 211: Release (10)
Release (10) Release (10) The 10-byte Release command (57h) enables the initiator to release unit reservations of the library as set using a previous Reserve command and optionally to perform a release for a third party initiator. Performing a unit release of a library that has no active reservations is not considered an error.
Page 212: Report Luns
Report LUNS Report LUNS The Report LUNS command (A0h) returns to the initiator the known LUNs to which the initiator can send commands. TABLE 4-111 Report LUNs Command Byte Operation Code (A0h) Ignored Reserved (0h) Select Report Reserved (0h) (MSB) Allocation Length (LSB) Reserved (00h)
Page 213: Report Luns Data Definition
Report LUNS Report LUNs Data Definition The library returns the following data for the Report LUNs command. TABLE 4-112 Report LUNs Data Byte 0 to 3 (MSB) LUN list length (LSB) 4 to 7 Reserved (00h) 8 to 15 (MSB) First LUN Descriptor (LSB) n -7...
Page 214: Report Target Port Groups (Hp Bridged)
Report Target Port Groups (HP Bridged) Report Target Port Groups (HP Bridged) The Report Target Port Groups command (A3h) requests that the library return the Target Port Group data for all ports. TABLE 4-114 Report Target Port Groups Command Byte Operation Code (A3h) Ignore Service Action (0Ah)
Page 215: Report Target Port Group Data Definitions
Report Target Port Groups (HP Bridged) Report Target Port Group Data Definitions The library returns the following data for the Report Target Port Groups command. TABLE 4-115 Report Target Port Groups Data Byte (MSB) Returned Data Length (LSB) Target Port Group Descriptors (MSB) First Target Port Group Descriptor (LSB)
Page 216 Report Target Port Groups (HP Bridged) Target Port Group Descriptor Data Definitions: PREF This bit indicates if the target port group is a preferred target port group. 0b indicates the target port group is not a preferred target port group. 1b indicates that the target port group is a preferred target port group.
Page 217: Target Port Descriptor Data
Report Target Port Groups (HP Bridged) Target Port Descriptor Data TABLE 4-117 Target Port Descriptor Data Byte Reserved (00h) 0 to 1 2 to 3 Relative Target Port Identifier Target Port Descriptor Data Definitions: Relative Target Port 0000h = No Target Port Identifier 0001h = Relative Target Port 1 0002h = Relative Target Port 2...
Page 218: Request Sense
Request Sense Request Sense The Request Sense command (03h) requests the library transfer sense data to the initiator. TABLE 4-118 Request Sense Command Byte Operation Code (03h) Ignored Reserved (00h) Desc (0h) Reserved (00h) Reserved (00h) Allocation Length Control Byte Request Sense Command Definitions: Desc The Desc bit indicates which sense data format shall be returned.
Page 219: Sense Data
Request Sense Sense Data Sense data is available when: • The previous command to the specified I_T_L nexus terminated with Check Condition status. Multiple errors might occur during the processing of a single SCSI command. The sense key reflects the first error that occurred. •...
Page 220: Request Sense Data Definitions
Request Sense Request Sense Data Definitions TABLE 4-119 shows the Request Sense Data Definitions. TABLE 4-119 Request Sense Data Byte Valid (0) Error Code (70h) Segment Number (00h) Reserved (0h) Sense Key (MSB) Information (00h) (LSB) Additional Sense Length (n-7) (MSB) Command Specific Information (00h) (LSB)
Page 221 Request Sense Additional Sense Code The Additional Sense Code (ASC) field, with the Sense Key and Additional Sense Code Qualifier fields, describes the error. Additional Sense Code The Additional Sense Code Qualifier (ASCQ) field, with the Sense Key and Qualifier Additional Sense Code fields, describes the error.
Page 222: Sense Key
Request Sense Sense Key The Sense Key field provides basic information about an error. TABLE 4-120 lists the Sense Keys with an explanation for each code. The Sense Key field, with the Additional Sense Code and Additional Sense Code Qualifier fields, provides a description about the error.
Page 223: No Sense Key
Request Sense No Sense Key The library returns a No Sense Key (00h) when there is no sense data to report, or when no real error has occurred and the host should resend the command. The following table describes the ASC and ASCQ values that go along with No Sense Key. TABLE 4-121 No Sense Keys Description Sense Key...
Page 224: Medium Errors Sense Key Codes
Request Sense Not Ready, Logical Unit Offline This sense data indicates that the library is offline and cannot process the command. Not Ready, Maintenance Mode The library was placed in maintenance mode from the operator panel or user interface. Not Ready, Cleaning Cartridge Installed The library is performing an Auto Clean function on the data transfer element (tape drive) requested.
Page 225: Hardware Error Sense Key
Request Sense Hardware Error Sense Key The library generates a Hardware Error sense key if a hardware or firmware error is detected during command execution. The following pages describe the conditions that generate hardware errors. TABLE 4-124 Hardware Error Sense Keys Description Sense Key ASCQ...
Page 226: Illegal Request Sense Key
Request Sense Illegal Request Sense Key Any illegal parameters in a command descriptor block (CDB) or parameter list for a particular command generate an Illegal Request sense key (see TABLE 4-125). In some cases, additional information is available in Byte 15 of the sense data, which includes the sense-key-specific-value (SKSV) and command/data (C/D) fields.
Page 227: Unit Attention Sense Key
Request Sense Unit Attention Sense Key The library generates a Unit Attention sense key for all initiators if the library needs to inform the host of an asynchronous event. The following pages describe library conditions that generate Unit Attention errors. TABLE 4-126 Unit Attention Sense Keys Description Sense Key...
Page 228 Request Sense Target Reset The HP Bridged Tape Drive generates this type of Unit Attention to all initiators after the library is clear of all I/O processes following the Target reset. LUN Reset The HP Bridged Tape Drive generates this type of Unit Attention to all initiators after the library is clear of all I/O processes following the LUN reset.
Page 229: Aborted Command Sense Key
Request Sense Aborted Command Sense Key The library generates an Aborted Command error code when a SCSI command is aborted because of a SCSI protocol error. The initiator might not register a Check Condition status related to these errors because of the nature of the aborted commands, but the sense data is available.
Page 230 Request Sense Command Overlap The library detected another command from an initiator while one was already in process. 230 SL150 Interface Reference Manual Julyl 2017...
Page 231: Request Volume Element Address
Request Volume Element Address Request Volume Element Address The Request Volume Element Address command (B5h) requests that the library return the results of a previous Send Volume Tag command. TABLE 4-128 Request Volume Element Address Command Byte Operation Code (B5h) Ignored VolTag Reserved (0h)
Page 232 Request Volume Element Address Allocation Length Specifies the length in bytes of the space allocated by the initiator for the transfer of element descriptors. Only complete element descriptors are transferred. Element descriptors are transferred until one of the following conditions is met: All available element descriptors of the type specified in the Element Type Code have been transferred.
Page 233: Volume Element Address Header Definition
Request Volume Element Address Volume Element Address Header Definition The Volume Element Address Header is sent once for each command. TABLE 4-129 Volume Element Address Header Byte (MSB) First Element Address Reported (LSB) (MSB) Number of Elements Available (LSB) Reserved (0h) Send Action Code (5h) (MSB) Byte Count of Report Available (all pages, n-7)
Page 234: Reserve (6)
Reserve (6) Reserve (6) The 6-byte Reserve command (16h) allows the initiator to perform unit reservations. Unit reservations are reservations of the library as a whole. TABLE 4-130 Reserve Command Byte Operation Code (16h) Ignored Obsolete (0h) Obsolete (00h) 3 to 4 Obsolete (00h) Control Byte Other Commands and Reservations...
Page 235: Reserve (10)
Reserve (10) Reserve (10) The 10-byte Reserve command (56h) allows the initiator to perform unit reservations. Unit reservations are reservations of the library as a whole. Another capability of the Reserve (10) command as opposed to the Reserve (6) command is the ability to do third party reservations. The third party reservation allows the reservation of a logical unit within a logical unit on behalf of another SCSI device.
Page 236: Other Commands And Reservations
Reserve (10) Other Commands and Reservations Unit reservations are released or canceled by: • A Release command from the initiator that owns the reservation (original initiator or the third party) • A Task Management reset: • Target Reset • LUN Reset •...
Page 237: Send Diagnostic
Send Diagnostic Send Diagnostic The Send Diagnostic command (1Dh) requests the library to perform a self-diagnostic test. The library accepts this command for compatibility, but does not perform any action. TABLE 4-132 Send Diagnostic Command Byte Operation Code (1Dh) Ignored Rsvd SelfTest DevOfl...
Page 238: Send Volume Tag
Send Volume Tag Send Volume Tag The Send Volume Tag command (B6h) is a request for the library to transfer a volume tag template. The template corresponds to a VOLSER label template and is used by the library to search for desired elements. A subsequent Request Volume Element Address command is used to transfer the results of this search.
Page 239: Send Volume Tag Parameter List
Send Volume Tag Parameter List Length This field indicates the length in bytes of the Parameter List that follows the command: 00h = No data is transferred. 28h = A Volume Identification Template is transferred. A value of 0 is not considered an error. Send Volume Tag Parameter List The Send Volume Tag command requires a parameter list that defines the volume template to search for.
Page 240: Test Unit Ready
Test Unit Ready Test Unit Ready The Test Unit Ready command (00h) allows the initiator to determine if the library is powered-on and ready to accept additional commands. This is not a request for a library self-test. The Test Unit Ready command returns a Good status if the library is ready to accept additional commands.
Page 241: Locations
Locations This appendix describes the SL150 Modular Library System walls (sides), tape slots (also named cells in prior interface manuals), and location scheme. Library Walls There are two types of walls in the library: 1. Left side wall, which consists of a 15-cartridge slot magazine array 2.
Page 242: Element Mapping
Tape Slot Locations Element Mapping TABLE A-1 shows the starting element address and the maximum number of each element type when the SL150 library is installed with 15 modules. Note – The mailslots allow an operator to insert or remove cartridges during library operations.
Page 243: Library Configuration And Slot Maps
Tape Slot Locations Library Configuration and Slot Maps FIGURE A-1 shows a library with a base module, no reserved cells and the standard mailslot configuration. FIGURE A-2 shows a library with 2 modules, no reserved cells, and the expanded mailslot configuration. FIGURE A-3 shows a library with 10 modules, 3 reserved cells, and the standard mailslot configuration.
Page 244: Configuration
Tape Slot Locations FIGURE A-2 Non-Partitioned 2 Module Library with No Reserved Cells and the Expanded Mailslot Configuration 1. Module 1 (Base) 2. Robot 3. Power supplies 4. Tape drives 5. Standard mailslots 6. Mailslot expansion 7. Right magazine front 8.
Page 245: Figuration
Tape Slot Locations FIGURE A-3 Non-Partitioned 10 Module Library with 3 Reserved Cells and the Standard Mailslot Configuration 1. Module 1 (Base) 2. Robot 3. Power supplies 4. Standard mailslots 5. Left magazine front 6. Right magazine front 7. Storage slots 8.
Page 246: Figuration
Tape Slot Locations FIGURE A-4 Non-Partitioned 15 Module Library with 3 Reserved Cells and the Standard Mailslot Configuration 1. Module 1 (Base) 2. Robot 3. Power supplies 4. Standard mailslots 5. Left magazine front 6. Right magazine front 7. Storage slots 8.
Page 247: Capacity
Tape Slot Locations Capacity TABLE A-3 shows the Number of Storage Slots, Mailslots, and Tape Drive Slots as Expansion Modules are added to the library configuration. TABLE A-3 Storage Slot, Mailslot, and Tape Drive Slots for Different Configurations Standard Mailslot Expanded Mailslot Configuration Configuration...
Page 248 Tape Slot Locations 248 SL150 Interface Reference Manual Julyl 2017...
Page 249: Partitioning Overview
Partitioning Overview The SL150 library can be partitioned into a maximum of eight distinct sections. Briefly stated, this means that instead of one library—with all its cartridge slots, tape drives, and mailslots—being a single entity, the library and these components can now be divided into sections or partitions.
Page 250: Partitioning-Feature
Partitioning—General Partitioning—Feature The SL150 library supports one to eight partitions. The customer has the choice of a non-partitioned library or a library with one to eight partitions. When a partitioned library is desired, the administrator enables the Library Partitioning option and adds the desired number of partitions. The administrator configures each partition with the following: •...
Page 251: Dard Mailslot Configuration
Partitioning—General FIGURE B-1 Example of a 10 Modular Tape Library with 2 Partitions, 3 Reserved Cells, and the Standard Mailslot Configuration 1. Module 1 (Base) 2. Partition 1 3. Partition 2 4. Robot 5. Power supplies 6. Tape drives 7. Standard Mailslots 8.
Page 252: Partitioning-Shared Mailslot Behavior
Partitioning—General FIGURE B-1 Example of a 10 Modular Tape Library with 2 Partitions, 3 Reserved Cells, and the Standard Mailslot Configuration 9. Right magazine front 10. Module 10 (Expansion) 11. Partition 1 resource 12. Partition 2 resource 13. Shared resource 14.
Page 253: Table B-1 Scsi Commands Affected By The Shared Mailslot Assignment
Partitioning—General TABLE B-1 shows how the SCSI Move and SCSI Read Element Status commands are affected by the shared mailslot assignment. For the purposes of this example, the library has been configured with two partitions. The library supports up to eight partitions.
Page 254: Partitioning-Removing The Feature
TABLE B-2 shows the conditions under which the shared mailslot is either locked or unlocked. A value of "ignored" indicates that the Prevent/Allow Media Removal state for the associated partition does not matter. For the purposes of this example, the library has been configured with two partitions. The library supports up to eight partitions.
Page 255: Glossary
Glossary This glossary defines terms and abbreviations in this publication. Some of the definitions are taken from other glossaries. The letters in the parentheses that follow some definitions indicate the source of the definition: (A) The American National Standard Dictionary for Information Systems, ANSI X3.172- 1990, copyright 1990 by the American National Standards Institute (ANSI).
Page 256 cartridge A storage device that consists of magnetic tape on a supply reel in a protective housing. The spine of the cartridge usually contains a label listing the volume identification number. Also called tape, tape cartridge, tape volume, or cassette. cartridge access port (CAP) See mailslot.
Page 257 expansion chassis The sheet metal and plastic chassis that makes up the framework for modules 2 - 15 (see Module X (2, 3, ..., 15)). export The action in which the device places a cartridge into the mailslot so that the operator can remove the cartridge.
Page 258 hand The robotic mechanism that grabs cartridges and moves them between slots and the drive. It is a component of the arm. The hand has a reach mechanism that gets cartridges from slots or drives and puts them into slots or drives. The hand also has a wrist mechanism that rotates the hand to allow it to reach cartridges on either side or the drives at the back of the library.
Page 259 LC connector A standard connector for 2-Gbps or 4-Gbps Fibre Channel data transfer. This type of connector is used on fiber-optic cables. Light emitting diode. An electronic device that lights up when electricity is passed through it. left magazine A plastic assembly containing 15 Tape Slots that can be inserted into the left side (as viewed from the front) of Modules 1-15.
Page 260 midplane A card mounted in the Base Chassis and Expansion Chassis. The card is identical whether used in a Base Chassis or an Expansion Chassis. This card is behind the tape slots and in front of the tape drives. Other cards connect to it either by direct connection or via a cable.
Page 261 port A specific communications end point within a host. A port is identified by a port number. (IBM) (2) In Fibre Channel, an access point in a device where a link attaches. An activity in which a robot places a cartridge into a slot or drive. power supply An AC to DC power supply.
Page 262 slot An empty location into which something else may be placed. Most commonly used when referring to the locations in the magazine or mailslot where tape cartridges are placed. Power supplies and drives are also placed in slots. switch In Fibre Channel technology, a device that connects Fibre Channel devices together in a fabric.
Page 263 expansion cable. Module X (2, 3, ..., 15). Z mechanism The robotic assembly mounted at the back of the robot that raises and lowers the arm. The Z mechanism includes a motor, gears, the bullwheel, and the wires and pulleys that hold the arm.
Page 264 264 SL150 Interface Reference Manual Julyl 2017...
Page 265: Index
Index control byte 27 Addressing USER Physical 241 element types 99 Expanders 16 busy status 29 good status 29 cartridges locations Initialize Element Status 30 diagnostic & cleaning 247 Initiators 15 placement in slots 241 Inquiry 32 CDB 21, 25 check condition 29 command control byte 27...
Page 266 Fibre Channel Disconnect/Reconnect 81, 137 SAS Shared Port Control Mode 151 Fibre Channel Logical Unit 85, 109, 141 Fibre Channel Port Control 65, 87, 111, 143 Informational Exceptions TapeAlert 53, 95 tape drive 200, 205 Informational Exceptions TapeAlert Control TapeAlert flags 54 124, 155 Targets 16 Informational Exceptions TapeAlerts 73...

Oracle StorageTek SL150 Reference Manual

List of Figures

List of Tables

Preface

1 General Information

2 Host Application Best Practices

3 Operation and Configuration Details

4 Command Set

Locations

Partitioning Overview

Glossary

Index

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Oracle StorageTek SL150

Summary of Contents for Oracle StorageTek SL150
