SDM-300A Satellite Modem
B.4

Status Commands/Responses

B.4.1

Modulator Configuration Status

Modulator Command:
Config. Response:
Status
Rev. 4
<add/MCS_'cr'
>add/MCS_'cr'
RF_xxx'cr'
MF_nnn.nnnnnnn'cr'
MR_nnnn_mmmm.mmm'cr'
AMRA_nnnn_mmmm.mmm'cr'
AMRB_nnnn_mmmm.mmm'cr'
AMRC_nnnn_mmmm.mmm'cr'
AMRD_nnnn_mmmm.mmm'cr'
AMRV_nnnn_mmmm.mmm'cr'
MPO_snn.n'cr'
MOP_snn.n'cr'
SE_xxx'cr'
DENC_xxx'cr'
MT_xxxxx'cr'
MET_xxx'cr'
COM_xxxxxx'cr'
MRC_xxx'cr'
MSR_xxx'cr'
RSEN_xxx'cr'
TDA_xxx'cr'
TRSI_xx'cr'
T310_xxx'cr''lf']
RF Output
Modulator Frequency
Modulator Rate
Preset 'A' Assignment
Preset 'B' Assignment
Preset 'C' Assignment
Preset 'D' Assignment
Preset 'V' Assignment
Modulator Power Offset
Modulator Output Power
Scrambler Enable
Differential Encoder
Modulator Type
Modulator Encoder Type
Carrier Only Mode
Modulator Reference Clock
Modulator Spectrum Rotation
Reed-Solomon Encoder
Transmit BPSK Data Ordering
TX Reed-Solomon Interleave Value
TX 8PSK 2/3 IESS-310 Operation
The modulator configuration status command causes a block
of data to be returned by the addressed modem. The block of
data reflects the current configuration status of the modulator
module. Additional configuration status of new options and
features will always be appended to the end.
Remote Control Operation
B–21
