CDM-710G High-Speed Satellite Modem
Front Panel Operation
6.3.5.1 (SELECT:) Save/Load
Save Config to Loc: 9
Empty
Using Loc 9: as the example, if Save is selected and no configuration has been saved, the second
line reads 'Empty', as shown in the preceding example.
However, if the selected Loc: 9 already contains data, what displays is similar to the next example:
Save Config to Loc: 9
01:02:43
The user is shown the time and date stamp of the previously stored configuration, for identification
purposes.
Select the location where the current configuration is to be stored using the
press . There are 10 available locations, numbered 0 through 9.
ENTER
If the selected location does not contain a previously stored configuration, the following screen is
displayed:
New Config has been
Saved to Loc 9
However, if the selected location does contain a previously stored configuration, the following
screen is displayed:
Loc 0 Contains Data !
Overwrite? NO YES (
Selecting Yes overwrites the existing configuration at the selected location.
Select No or Yes using the
6.3.5.2 (SELECT:) Save/Load
Load Config from Loc: 9
11:02:43
Using Loc: 9 as the example, if Load is selected and there is a configuration stored at the selected
location, what displays is similar to the preceding example. Note that the stored configuration is
identified with a date and time stamp.
If the selected location contains no data, what displays is similar to the next example:
Load Config from Loc: 9
Empty
Select the location from where the current configuration is to be loaded using the
then press
ENTER
( E)
05/08/05 (
(E)
E)
arrow keys, then press
05/08/05 ( E)
( E)
. There are 10 locations numbered 0 through 9..
Save
E)
ENTER
Load
6–48
MN-CDM710G
arrow keys, then
.
arrow keys,
Revision 1
