xStack® DES-3528/DES-3552 Series Layer 2 Stackable Fast Ethernet Managed Switch Web UI Reference Guide

CFM Port Settings

This table is used to enable or disable the connectivity fault management function on a per port basis. CFM is disabled
on all ports by default.
To view this window, click OAM > CFM > CFM Port Settings, as shown below:
The fields that can be configured are described below:
Parameter
Unit
From Port / To Port
State
Click the Apply button to implement the changes made.
Figure 10-8 CFM Port Settings window
Description
Select the unit to configure.
Use the drop-down menus to select a port or range of ports to configure.
Use the drop-down menu to enable or disable the function.
298
