xStack® DES-3528/DES-3552 Series Layer 2 Stackable Fast Ethernet Managed Switch Web UI Reference Guide
The fields that can be configured are described below:
Parameter
Access ID (1-100)
Action
Time Range Name
Ports
Click the Apply button to accept the changes made.
Click the <<Back button to discard the changes made and return to the previous page.
After clicking the Show Details button in the CPU Access Rule List, the following page will appear:
Figure 7-32 Add CPU Access Rule (IPv4 ACL)
Description
Type in a unique identifier number for this access. This value can be set from 1 to 100.
Select Permit to specify that the packets that match the access profile are forwarded by
the Switch, according to any additional rule added (see below).
Select Deny to specify that the packets that match the access profile are not forwarded
by the Switch and will be filtered.
Tick the check box and enter the name of the Time Range settings that has been
previously configured in the Time Range Settings window. This will set specific times
when this access rule will be implemented on the Switch.
Ticking the All Ports check box will denote all ports on the Switch.
Figure 7-33 CPU Access Rule Detail Information (IPv4 ACL)
191
