xStack® DES-3528/DES-3552 Series Layer 2 Stackable Fast Ethernet Managed Switch Web UI Reference Guide
The fields that can be configured are described below:
Parameter
Unit
From Port / To Port
State
Mode
Click the Apply button to accept the changes made.

Voice VLAN OUI Settings

This page is used to configure the user-defined voice traffic's OUI. The OUI is used to identify the voice traffic. There
are a number of pre-defined OUIs. The user can further define the user-defined OUIs if needed. The user-defined OUI
cannot be the same as the pre-defined OUI.
To view the following window, click L2 Features > VLAN > Voice VLAN > Voice VLAN OUI Settings, as shown
below:
Figure 4-19 Voice VLAN Port Settings window
Description
Select the unit to configure.
Select a range of ports to be displayed.
Select the state of the port.
Select the mode of the port.
75
