Chapter 5

Local Route Settings

IPv4 Static/Default Route Settings

IPv4 Route Table
IPv6 Static/Default Route Settings
IPv6 Route Table
Policy Route Settings
IP Forwarding Table
Local Route Settings
This window is used to configure the IPv4 and IPv6 local route settings.
To view the following window, click L3 Features > Local Route Settings, as shown below:
The fields that can be configured are described below:
Parameter
IPv4 Local Route
IPv6 Local Route
Click the Apply button to accept the changes made for each individual section.
NOTE: IPv4 and IPv6 static routes are mutually exclusive and cannot be created at the same time on
DES-3528/DES-3552 Series switches.
IPv4 Static/Default Route Settings
The Switch supports static routing for IPv4 and IPv6 formatted addressing. Users can create up to 16 static route
entries for IPv4 or 16 static route entries for IPv6. For IPv4 static routes, once a static route has been set, the Switch
will send an ARP request packet to the next hop router that has been set by the user. Once an ARP response has
been retrieved by the Switch from that next hop, the route becomes enabled. However, if the ARP entry already exists,
an ARP response will not be sent.
NOTE: IPv4 and IPv6 static routes are mutually exclusive and cannot be created at the same time on
DES-3528/DES-3552 Series switches.
L3 Features
Figure 5-1 Local Route Settings window
Description
Click the radio buttons to enable or disable IPv4 local route. The function is enabled by
default.
Click the radio buttons to enable or disable IPv6 local route. The function is disabled by
default.
