Duld Settings - D-Link DES-3528 - xStack Switch - Stackable Reference Manual

xStack® DES-3528/DES-3552 Series Layer 2 Stackable Fast Ethernet Managed Switch Web UI Reference Guide
The fields that can be configured are described below:
Parameter
Port
Port List
Click the Clear button to clear all the information entered in the fields.

DULD Settings

The window is used to configure unidirectional link detection on ports.
Unidirectional link detection provides discovery mechanism based on 802.3ah to find its neighbor. If the discovery can
complete in the configured discovery time, it concludes the bi-directional link. Otherwise, it starts to detect the link
status.
To view this window, click OAM > DULD Settings, as shown below:
Figure 10-17 Ethernet OAM Statistics window
Description
Use the drop-down menu to specify the port number.
Specify which ports' counter to show. Tick All Ports to view all ports.
306
