xStack® DES-3528/DES-3552 Series Layer 2 Stackable Fast Ethernet Managed Switch Web UI Reference Guide
The fields that can be configured are described below:
Parameter
Unit
Port
Time Interval
Record Number
Show/Hide
Click the Apply button to accept the changes made for each individual section.

Statistics

Port Statistics

Packets
The Web manager allows various packet statistics to be viewed as either a line graph or a table. Six windows are
offered.
Received (RX)
To select a port to view these statistics for, select the port by using the Port pull-down menu. The user may also use
the real-time graphic of the Switch at the top of the web page by simply clicking on a port.
To view this window, click Monitoring > Statistics > Port Statistics > Packets > Received (RX), as shown below:
Description
Select the unit to configure.
Use the drop-down menu to choose the port that will display statistics.
Select the desired setting between 1s and 60s, where "s" stands for seconds. The
default value is one second.
Select number of times the Switch will be polled between 20 and 200. The default value
is 200.
Check whether or not to display Port Util.
311
