xStack® DES-3528/DES-3552 Series Layer 2 Stackable Fast Ethernet Managed Switch Web UI Reference Guide
Chapter 11

Utilization

Statistics
Mirror
sFlow
Ping Test
Trace Route
Peripheral
Utilization

CPU Utilization

Users can display the percentage of the CPU being used, expressed as an integer percentage and calculated as a
simple average by time interval.
To view this window, click Monitoring > Utilization > CPU Utilization, as shown below:
The fields that can be configured are described below:
Parameter
Time Interval
Record Number
Show/Hide

Monitoring

Figure 11-1 CPU Utilization window
Description
Select the desired setting between 1s and 60s, where "s" stands for seconds. The
default value is one second.
Select number of times the Switch will be polled between 20 and 200. The default value
is 200.
Check whether or not to display Five Seconds, One Minute, and Five Minutes.
309
