xStack® DES-3528/DES-3552 Series Layer 2 Stackable Fast Ethernet Managed Switch Web UI Reference Guide
Record Number
64
65-127
128-255
256-511
512-1023
1024-1518
Show/Hide
Click the Apply button to accept the changes made for each individual section.
Click the Clear button to clear all statistics counters on this window.
Click the View Table link to display the information in a table rather than a line graph.
Click the View Graphic link to display the information in a line graph rather than a table.

VLAN Counter Statistics

To view this window, click Monitoring > Statistics > VLAN Counter Statistics, as shown below:
The fields that can be configured are described below:
Parameter
VID List
VLAN name
Port List
Click the Clear button to clear all the information entered in the fields.
Click the Find button to locate a specific entry based on the information entered.
Click the View All button to display all the VLAN counter statistics.
Click the Clear All button to remove all the entries listed in the table.
value is one second.
Select number of times the Switch will be polled between 20 and 200. The default value is
200.
The total number of packets (including bad packets) received that were 64 octets in length
(excluding framing bits but including FCS octets).
The total number of packets (including bad packets) received that were between 65 and
127 octets in length inclusive (excluding framing bits but including FCS octets).
The total number of packets (including bad packets) received that were between 128 and
255 octets in length inclusive (excluding framing bits but including FCS octets).
The total number of packets (including bad packets) received that were between 256 and
511 octets in length inclusive (excluding framing bits but including FCS octets).
The total number of packets (including bad packets) received that were between 512 and
1023 octets in length inclusive (excluding framing bits but including FCS octets).
The total number of packets (including bad packets) received that were between 1024 and
1518 octets in length inclusive (excluding framing bits but including FCS octets).
Check whether or not to display 64, 65-127, 128-255, 256-511, 512-1023, and 1024-1518
packets received.
Description
Click the radio button and enter a list of VLAN ID.
Click the radio button and enter a VLAN name.
Enter a list of ports
322
