xStack® DES-3528/DES-3552 Series Layer 2 Stackable Fast Ethernet Managed Switch Web UI Reference Guide
Parameter
LLDP State
LLDP Forward Message
Message TX Interval (5-
32768)
Message TX Hold
Multiplier (2-10)
LLDP ReInit Delay (1-10)
LLDP TX Delay (1-8192)
LLDP Notification
Interval (5-3600)
Click the Apply button to accept the changes made for each individual section.

LLDP Port Settings

On this page the user can configure the LLDP port parameters.
To view the following window, click L2 Features > LLDP > LLDP Port Settings, as shown below:
Description
Click the radio buttons to enable or disable the LLDP feature.
When LLDP is disabled this function controls the LLDP packet forwarding message
based on individual ports. If LLDP is enabled on a port it will flood the LLDP packet to
all ports that have the same port VLAN and will advertise to other stations attached to
the same IEEE 802 LAN.
This interval controls how often active ports retransmit advertisements to their
neighbors. To change the packet transmission interval, enter a value in seconds (5 to
32768).
This function calculates the Time-to-Live for creating and transmitting the LLDP
advertisements to LLDP neighbors by changing the multiplier used by an LLDP
Switch. When the Time-to-Live for an advertisement expires the advertised data is
then deleted from the neighbor Switch's MIB.
The LLDP re-initialization delay interval is the minimum time that an LLDP port will
wait before reinitializing after receiving an LLDP disable command. To change the
LLDP re-init delay, enter a value in seconds (1 to 10).
LLDP TX Delay allows the user to change the minimum time delay interval for any
LLDP port which will delay advertising any successive LLDP advertisements due to
change in the LLDP MIB content. To change the LLDP TX Delay, enter a value in
seconds (1 to 8192).
LLDP Notification Interval is used to send notifications to configured SNMP trap
receiver(s) when an LLDP change is detected in an advertisement received on the
port from an LLDP neighbor. To set the LLDP Notification Interval, enter a value in
seconds (5 to 3600).
