xStack® DES-3528/DES-3552 Series Layer 2 Stackable Fast Ethernet Managed Switch Web UI Reference Guide
To view this window, click Network Application > DHCP > DHCP Relay > DHCP Relay Interface Settings, as shown
below:
The fields that can be configured are described below:
Parameter
Interface Name
Server IP
Click the Apply button to accept the changes made.
DHCP Relay VLAN Settings
To view this window, click Network Application > DHCP > DHCP Relay > DHCP Relay VLAN Settings, as shown
below:
The fields that can be configured are described below:
Parameter
Server IP
Action
VID List
Click the Apply button to implement the changes made.

DHCP Relay Option 60 Server Settings

On this page the user can configure the DHCP relay option 60 server parameters.
To view this window, click Network Application > DHCP > DHCP Relay > DHCP Relay Option 60 Server Settings,
as shown below:
Figure 9-4 DHCP Relay Interface Settings window
Description
The IP interface on the Switch that will be connected directly to the server.
Enter the IP address of the DHCP server. Up to four server IPs can be configured per IP
interface.
Figure 9-5 DHCP Relay VLAN Settings window
Description
Enter the IP address of the DHCP server. Up to four server IPs can be configured per
VLAN.
Use the drop-down menu to add or delete the VLAN.
Enter a list of VLANs.
278
