xStack® DES-3528/DES-3552 Series Layer 2 Stackable Fast Ethernet Managed Switch Web UI Reference Guide

Ethernet OAM Event Log

The window is used to display the Ethernet OAM event log information. The Switch can record up to 1000 event logs.
This event log has more detailed information than system log. Each OAM event is recorded in both OAM event log and
system log.
To view this window, click OAM > Ethernet OAM > Ethernet OAM Event Log, as shown below:
The fields that can be configured are described below:
Parameter
Port
Port List
Click the Find button to locate a specific entry based on the information entered.
Click the Clear button to clear all the information entered in the fields.

Ethernet OAM Statistics

The window is used to display Ethernet OAM statistics information.
To view this window, click OAM > Ethernet OAM > Ethernet OAM Statistics, as shown below:
Figure 10-16 Ethernet OAM Event Log window
Description
Use the drop-down menu to specify the port number.
Specify which ports' counter to show. Tick All Ports to view all ports.
305
