are Emergency (0), Alert (1), Critical (2), Error (3), Warning (4), Notice (5), Information(6) and
Debug(7).
Click the Apply button to accept the changes made.

Time Range Settings

Time range is a time period that the respective function will take an effect on, such as ACL. For example, the
administrator can configure the time based ACL to allow users to surf the Internet on every Saturday and every Sunday,
meanwhile to deny users to surf the Internet on weekdays.
The user may enter up to 64 time range entries on the Switch.
To view the following window, click System Configuration > Time Range Settings, as shown below:
The fields that can be configured are described below:
Parameter Description
Range Name Enter a name of no more than 32 alphanumeric characters that will be used to identify this time
range on the Switch. This range name will be used in the Access Profile table to identify the
access profile and associated rule to be enabled during this time range.
Hours This parameter is used to set the time in the day that this time range is to be enabled using the
following parameters:
Start Time - Use this parameter to identify the starting time of the time range, in hours, minutes
and seconds, based on the 24-hour time system.
End Time - Use this parameter to identify the ending time of the time range, in hours, minutes
and seconds, based on the 24-hour time system.
Weekdays Use the check boxes to select the corresponding days of the week that this time range is to be
enabled. Tick the Select All Days check box to configure this time range for every day of the
week.
Click the Apply button to accept the changes made. Current configured entries will be displayed in the table in the
bottom half of the window shown above.

Time Settings

Users can configure the time settings for the Switch.
To view the following window, click System Configuration > Time Settings, as shown below:
Figure 2-15 Time Range Settings window
