xStack® DES-3528/DES-3552 Series Layer 2 Stackable Fast Ethernet Managed Switch Web UI Reference Guide
The fields that can be configured are described below:
Parameter
Unit
From Port / To Port
State
Max Authenticating
Host (0-50)
Aging Time (1-1440)
Block Time (0-300)
Idle Time (1-1440)
Click Apply to implement changes made.
Figure 8-42 JWAC Port Settings window
Description
Select the unit to configure.
Use the drop-down menus to select a port or range of ports to configure.
Specify the state of the configured ports.
Specify the maximum number of host process authentication attempts allowed on each
port at the same time.
Specify the period of time that a host will keep in authenticated state after it successes to
authenticate. Enter a value between 1 and 1440 minutes. The default setting is 1440
minutes. To maintain a constant Port Configuration, tick the Infinite check box.
Specify the period of time that a host will keep in a blocked state after it fails to
authenticate. Enter a value between 0 and 300 seconds. The default setting is 60
seconds.
Specify the period of time during which there is no traffic for an authenticated host and
the host will be moved back to the unauthenticated state. Enter a value between 1 and
1440 minutes. Tick the Infinite check box so that the Idle state of the authenticated host
on the port will never be checked. The default setting is Infinite.
