Jwac User Settings; Jwac Authentication State - D-Link DES-3528 - xStack Switch - Stackable Reference Manual

xStack® DES-3528/DES-3552 Series Layer 2 Stackable Fast Ethernet Managed Switch Web UI Reference Guide

JWAC User Settings

To view this window, click Security > JWAC > JWAC User Settings, as shown below:
The fields that can be configured are described below:
Parameter
User Name
Password
Confirm Password
VID (1-4094)
Click the Add button to create a new entry.
Click the Delete All button to remove all the entries listed.
Click the Edit button to re-configure the specific entry.
Click the Delete button to remove the specific entry.

JWAC Authentication State

Users can view and delete the hosts for JWAC authentication.
To view this window, click Security > Japanese Web-based Access Control (JWAC) > JWAC Authentication State,
as shown below:
The fields that can be configured are described below:
Parameter
Port List (e.g.: 1:1,
Figure 8-43 JWAC User Settings window
Description
Enter a username of up to 15 alphanumeric characters.
Enter the password of the user. This field is case-sensitive and must be a complete
alphanumeric string.
Retype the password entered in the previous field.
Enter a VLAN ID up to 4094.
Figure 8-44 WAC Authentication State window
Description
Use the drop-down menus to select the desired range of ports and tick the appropriate
240
