Installation
2-1-2

Installing FinsGateway

Using FinsGateway
Version 3
1,2,3...
3. The program will suggest a system restart when it finishes.
Do not proceed to the next step without restarting the computer. If the in-
stallation is continued without restarting the computer, the FinsGateway
will not operate properly.
After installing FinsGateway Version 3, install FinsGateway Update 3.12.
Installation of FinsGateway Version 3
1. Select one of the following directories from within the Fgwv3\FGW3ee fold-
er in the CD-ROM. (Select the directory corresponding to the communica-
tions method being used in the PLC.)
Folder name
Clk
Select this directory when connecting the PLC and personal computer (the
CX-Process Tool and the CX-Process Monitor Plus) via Controller Link
using a Controller Link Support Board (ISA bus) installed in the computer.
Clk (PCI)
Select this directory when connecting the PLC and personal computer (the
CX-Process Tool and the CX-Process Monitor Plus) via Controller Link
using a Controller Link Support Board (PCI bus) installed in the computer.
Etn
Select this directory to connect the personal computer (the CX-Process
Tool and the CX-Process Monitor Plus) to the PLC via Ethernet.
Serial
Select this directory to connect the personal computer (the CX-Process
Tool and the CX-Process Monitor Plus) to the PLC via the Host Link.
The following step applies to Host Link SYSWAY connections.
2. Use a program such as Windows Explorer to open the CD-ROM and dou-
ble-click the following icon to start the Setup.exe file in the CD-ROM's Se-
rial/disk1 directory.
The following screen will be displayed.
Contents
Section 2-1
31
