Reading/Writing Function Block ITEMs
Reversible Motor Manipulator (Block Model 223)
ITEM ITEM Tag
type ITEM
Contact 000 MT_SW Stop block operation
input command(0: Cancel
stop, 1: Stop)
012 S2 AUTO-FWD input
0:OFF; 1:ON
013 S3 AUTO-REV input
0:OFF; 1:ON
014 S4 MAN-FWD input
0:OFF; 1:ON
016 S6 MAN-REV input
0:OFF; 1:ON
018 S8 FWD answer input
0:OFF; 1:ON
019 S9 REV answer input
0:OFF; 1:ON
023 U3 Answer error
(1:error)
Analog 032 X1 CT input
input
Param- 033 H_SP CT input high alarm
eter setting
Contact 036 H CT input high alarm
output output
Contact 085 S4 Site manipulation
input switch input
(0:Central; 1:Site)
086 A/M_SW Auto/Manual switch-
ing
0: Manual, 1: Auto
Param- 099 OP_MK Label
eter
Note Only optional tags can be set.
Data Data
description range
Over-
view
Screen
0 or 1
0 or 1
0 or 1
0 or 1
0 or 1
0 or 1
0 or 1
0 or 1
–320.00 to
+320.00%
–320.00 to
+320.00%
0 or 1
0 or 1
0 or 1
0 to 15
CX-Process Monitor screen (R:Read W:Write)
Control Tuning Trend Batch
Screens Screens Screens Trend
Screen
R R
R R R
R R R
R/W R R
R/W R R
R R R
R R R
R R R
(Color)
R R R
R (–) R R
R R R
R R R
(Color)
R/W R R
R/W R R
Appendix A
Segment Graphic Annun- Alarm
Program Screens ciator
2 Screen Screens Screens
(See
note.)
R R R
R R R
R R R
R R/W R
R R/W
R R
R R
R R R R
R R
R R/W
R R R R
R R R
R R/W R
R R/W
