Omron CX-PROCESS MONITOR PLUS V2 - 01-2007 Operation Manual page 191

Creating Graphic Screens
Saving Grouped Graphic Objects
1,2,3...
Note
Loading Grouped Graphic Objects
1,2,3...
176
1. With the grouped object selected, select Save Group File from the File
Menu.
2. The Save As Dialog Box will be displayed.
Input the file name and click the Save Button.
The grouped graphic object data will be saved (file name extension: ITM).
Settings related to tags set for individual graphic objects will not be saved.
Set the tags as required when reading and using grouped graphic objects that
have been saved.
1. Select Load Group File from the File Menu.
2. The Open Dialog Box will be displayed. Select the group file that is to be
read, and click the Open Button.
3. The grouped graphic object will be loaded to the Graphic Screen.
Section 5-4
