Screen Configuration
Registering Segment
Program 2 Screens
1,2,3...
192
For example, if the destination is C:\BatchTrend, and the batch collection was
started on December 1, 2006, the folders will be created under
C:\BatchTrend\20061201\. (The underlined portion is the date on which the
batch collection was started.)
File Name
Specify the name of the file to be saved. (Note: Do not specify the file name
extension here.)
The actual name of the file that is saved will be as follows:
start_date-start_time-filename.csv
(The start date and the start time are the time information for when the
trend data collection was started for the file that is being saved.)
For example, if the name of the file being saved is BatchTrend, and the batch
collection was started at 16:15:10 on December 1, 2006, the file name
20061201-161510-BatchTrend.csv will be created automatically.
There are two types of Segment Program 2 Screens: a Segment Program 2
Monitor Screen and a Segment Program 2 Edit Screen. Up to 16 pairs of Seg-
ment Program 2 Screens can be registered.
1. Select Screen in the Overview Screen sub-elements using the Screen
Management Tree in the Builder Window.
2. Select Register Screen from the Settings Menu, or double-click Screen.
The dialog box displayed in step 2 of Registering Control Screens above
will be displayed.
3. Select Segment Program 2 Screen and then click the New Button. The fol-
lowing dialog box will be displayed.
Aside from the Segment Program 2 tags, one analog ITEM (PV, SP, MV, or
other analog signal) and one contact ITEM can be registered as an option-
al tag.
Specify analog or contact ITEMs using either method 1 or 2 below.
(1) Tag numbers (tag names) and tag ITEMs (PV, SP, or MV) for the func-
tion block.
(2) Tag numbers (tag names) for analog or contact ITEMs.
Click to select.
Double-click to omit step 2 of the
procedure.
Section 5-5
