CX-Process Monitor Plus Software Specifications

CX-Process Monitor Plus Specifications
Item
Product name
Model
Applicable PLC-series
Applicable Unit
Applicable Personal computer
computer
CPU
OS
Memory
Hard disk drive
Monitor
CD-ROM drive
Mouse
Printer
Sound board
Required software
Connecting Connection with CPU Unit
method (or Serial Communications
Board/Unit)
Connection via Controller
Link
Connection via Ethernet
Loop Control Unit/Board data specifica-
tion method
Offline operation functions
16
CX-Process Monitor Plus
WS02-LCMC1-EV2
CS/CJ-series
Loop Control Unit Ver. 2.0 or later
Loop Control Board
Process-control CPU Unit
Loop-control CPU Unit
IBM PC/AT or compatible
Min. required: Pentium MMX233 MHz or faster, Recommended: Celeron
400 MHz or faster
Microsoft Windows NT 4.0 (Service Pack 6a or higher), Windows 2000 Profes-
sional (Service Pack 4 or higher), Windows XP Professional (Operation is not
supported on Windows 95, 98, or ME.)
Min. required: 128 Mbytes, Recommended: 256 Mbytes or more
Min. required: 650 Mbytes of free space, Recommended: 800 Mbytes or more
of free space
Min. required: XGA, Recommended: XGA or higher, min. 1024 × 768 dots, 256
colors
At least one
Recommended: Microsoft mouse or compatible pointing device
Any printer supported by Microsoft Windows
1 board
FinsGateway (One of the following must be installed according to the commu-
nications method with the PLC.)
Serial Unit driver (Host Link)
Controller Link driver (Controller Link)
CLK (PCI) driver (Controller Link, PCI bus)
ETN_UNIT driver (Ethernet)
Using Fins- The computer is connected to the CPU Unit peripheral ports or
Gateway integrated RS-232C port, or RS-232C port of the Serial Com-
Serial Unit munications Unit. (Only a 1:1 connection is possible.)
version
– Connector cable:
When connecting to the CPU Unit peripheral ports: Model
CS1W-CN@@@ (2 m, 6 m)
When connecting to the CPU Unit's RS-232C port: Model
XW2Z@@@-@ (2 m, 5 m)
– Communications protocol with PLC: Host Link (not supported
on Peripheral bus)
Using Fins- Install the driver in a computer equipped with a Controller Link
Gateway CLK Support Board (PCI slot) to support communications between
(PCI) Driver the computer and PLCs equipped with a Controller Link Unit.
Using Fins- Install the driver in a computer equipped with a Controller Link
Gateway Support Board (ISA slot) to support communications between
Controller the computer and PLCs equipped with a Controller Link Unit.
Link driver
Using Fins- Install the FinsGateway ETN_UNIT driver on the computer on
Gateway which an Ethernet board is mounted to enable to enable com-
ETN_UNIT munications with the PLC on which the Ethernet Unit is
driver mounted.
CSV tags and tags for Monitor Plus (CSV monitor tags) are set using the CX-
Process Tool. These tags are used to specify Loop Control Unit/Board data.
Prepare user configuration screens for use in the online operation screen.
