Creating Graphic Screens
Text Box ( )
Input the text to be
displayed.
Set the font for the
text to be displayed.
164
Color Settings Tab
If No background color is not selected,
click to set the data background color.
For details on the Show/Hide Tag Settings Tab and the Flashing Tag Settings
Tab, refer to Common Settings for Graphic Objects in this section.
Used to display text input by the user.
Multiple lines can be displayed.
Setting Method
General Tab
Color Settings Tab
If No background color is selected, click
to set the text box background color.
For details on the Show/Hide Tag Settings Tab and the Flashing Tag Settings
Tab, refer to Common Settings for Graphic Objects in this section.
Section 5-4
Click to set the color for the numbers
to be displayed in the data.
Select this option to make the data
background transparent.
Select the type of frame to
enclose the text.
Click to set the color for the text to be
displayed in the text box.
Select this option to make the data
background transparent.
