Screen Configuration
Changing Monitor Tag File
Paths
182
CX-Process
Monitor Plus
Tag name:
Specify ABC
Loop Control
Unit/Board
Example 3
Specifying the Trend Screen trend as analog ITEM for tag name "IN1."
Tag name IN1
CX-Process
Monitor Plus
Tag name: Specify IN1
Loop Control
Unit/Board
Monitor Tag files are saved to the following directory with a fixed file name
when the Run Button in the Main Window is clicked.
Directory: Omron/CX-Process Monitor Plus/db (The underlined part is the
directory in which the CX-Process Monitor Plus is installed.)
File names: mtagmst and mtagsubmst
It is possible to create several tag file for Monitor Plus and switch between
them by changing the application path. In this way, by creating new Monitor
Tag files in a directory different from the default one, and changing the appli-
cation path to this directory, the Monitor Tag files that are used by CX-Process
Monitor Plus can be changed. The procedure is as follows:
Trend Screen
Tag ITEM: Specify MV
Trend Screen
Section 5-5
