System Information Settings
Alarm Stop Function All alarm sounds can be silenced when the specified tag is ON.
When this function is enabled and the specified tag is ON, all alarm sounds
(such as process alarms, system alarms, and annunciator alarms) will be
stopped.
Setting the Alarm Stop Tag
Click the Browse Button next to the Tag Name field to display the following
dialog box. Select the tag name of the tag that will control alarm sounds and
click the OK Button.
Contact tags in the user link table or internal switch tags can be specified as
alarm stop tags.
Note The following dialog box will be displayed if a tag name longer than 16 charac-
ters is input directly into this field. In this case, input an existing tag name that
is up to 16 characters long.
Section 5-6
If the alarm is enabled, all
alarm will be stopped when
the specified tag is ON.
Select the tag that will silence
alarms.
