Creating Graphic Screens
Ele- Object name
ments
Fixed Text box
objects
Parts Transmitter
Orifice
Instrument
Tempera-
ture meter
Figures and Images
Ele- Object name
ments
Figures Text
Line
Rectangle
Rectangle with
rounded corners
(Round rect)
Ellipse
Polygon
Images Image
156
Shape Function
(typical)
---
Shape Function
(typical)
---
---
---
---
---
---
Display image files
in BMP or JPG for-
mat
Specifications
Show/ Flashing
hide tag tag allo-
alloca- cation
tion
Yes Yes Text, type (3D display, display
frame 0 to 4, flat), font, color
(character and background col-
ors
Yes Yes Direction (up, down, right, left),
color (border line color and
background colors)
Yes Yes
Yes Yes
Yes Yes
Specifications
Show/ Flashing
hide tag tag allo-
alloca- cation
tion
Yes Yes Text string, font, color settings
(direct, tag settings), display
position, border lines (line
width, line style, color settings),
background color (color set-
tings)
Yes Yes Color settings (direct, tag set-
tings), border lines (line width,
line style, color settings)
Yes Yes Color settings (direct, tag set-
tings), border lines (line width,
line style, color settings), back-
ground color (color settings)
Yes Yes Color settings (direct, tag set-
tings), border lines (line width,
line style, corner color set-
tings), background color
(enable/disable, color settings)
Yes Yes Color settings (direct, tag set-
tings), border lines (line width,
line style, color settings), back-
ground color (enable/disable,
color settings)
Yes Yes Color settings (direct, tag set-
tings), border lines (line width,
line style, color settings), back-
ground color (enable/disable,
color settings)
Yes Yes Color settings (direct, tag set-
tings), border lines (line width,
line style, color settings), image
specification (direct, tag set-
tings)
