CX-Process Monitor Plus
CX-Process Monitor Plus Functions
---
User-defined Overview
screens
Control
Tuning
Trend
Batch Trend
Segment
Program 2
Graphic
Annunciator
Operation Guide OK (Display message
System Monitor
System screens Alarm Log
Operation Log
System Monitor
Log
Note
Screen Monitoring operating
status
---
OK (Display PV bar)
OK (Display PV, SP, and
MV trends for 1 loop)
OK (Display Control Block
or analog signal trends)
OK (Display Control Block
or analog signal trends)
OK (Display Segment
Program 2 trends)
OK (Display status for
contact or analog signal
graphics)
---
when Internal Switch is
turned ON)
OK (Display the run/stop
status for the Loop Con-
trol Unit/Board, display
Execution errors, RAM
checksum errors, and
battery errors, and moni-
tor the status of the CPU
Unit control mode, etc.)
---
---
OK (Displays run/stop
command history and
Execution error history
when an error occurs)
Only the following data can be monitored and set with the CX-Process Moni-
tor Plus and tag names must be set to enable monitoring and setting. Use CX-
Process Tool Ver. 3.2 or higher to set the tag names.
Controlling operation
---
OK (Change SP, switch
between auto/manual,
and perform manual oper-
ations)
OK (Change SP, and
change P, I, D, etc.)
---
---
OK (Run/stop operation
at the relevant Segment
Program 2 Block)
OK (Turn ON/OFF the
contact, and set the ana-
log value)
---
---
OK (Run/stop command
for the Loop Control Unit/
Board)
---
OK (Stores run operation
history, e.g., SP change,
etc.)
---
Section 1-1
Monitoring alarm status
OK
OK
OK (Change bar graph
colors)
OK
---
OK (Errors related to the
relevant Segment Pro-
gram 2 Block)
OK
OK (Use colors or sound
to notify of an alarm)
OK
OK
OK (Stored when an
alarm occurs)
OK
OK
3
