Basic Configuration Procedure

5-1

Basic Configuration Procedure

Select Omron, CX-Process Monitor Plus, CX-Process Monitor Plus from Windows Start Menu.
In the Main Window, click the Setup Button.
Enter the password.
In the Setup Dialog Box, click the System Monitor Builder Button, and set the communications conditions,
etc., in the System Monitor Setting Window. (Only if using serial communications, when starting the monitor
process, the FinsGateway Serial Unit may start depending on the communications conditions that have been
set.)
In the Setup Dialog Box, click the CRT Builder Button, and set the Builder window
1. Select Settings, Register Screen.
2. Select new screen type.
3. Click New.
4. Double-click Tag No., and select the tag name.
5. Double-click Detailed Settings, and make the
detailed settings.
In CRT Builder, select the Settings Menu, and then select Save, and then click the OK Button.
Set the main system settings under System Information. (Refer to 5-6 System Information Settings.)
Check the screen configuration that has been set. (Refer to 5-7 Checking Configurations.)
140
In the Setup Dialog Box, click the Graphic Builder Button, and then in the Graphic
Builder, create the Graphic Screen (including tag name selection, etc.,), and save.
1. Select Settings, Register Screen.
2. Select new screen type.
3. Click New.
4. Select the Graphic Screen that has been saved.
Section 5-1
