Creating Graphic Screens
Pipe ( )
Select the options for the
frame to be displayed
around the pipe.
158
Color Settings Tab
For details on the Show/Hide Tag Settings Tab and the Flashing Tag Settings
Tab, refer to Common Settings for Graphic Objects in this section.
The color is changed according to the ON/OFF status of the specified tag.
Setting Method
General Tab
Set the pipe colors for when the
specified contact ITEM is ON and OFF.
For details on the Show/Hide Tag Settings Tab and the Flashing Tag Settings
Tab, refer to Common Settings for Graphic Objects in this section.
Section 5-4
Click to set the fill color according
to the tag value.
Click to set the background color
for the tank.
Select the tag
name for the
function block.
Select the function block
ITEM for the above tag.
