CX-Process Monitor Plus
1-1-7

CX-Process Monitor Plus Setting and Monitoring Capabilities

Item
1. Register the function
blocks used for data
exchange.
2. Set the tag names.
3. Create the monitor tag file.
Note
20
The data that can be set and monitored using the CX-Process Monitor Plus is
listed in the following table.
Item
Function block data
Contact signals
Analog Sent to
signals Monitor Plus
Set from
Monitor Plus
The following items must be set in advance using the CX-Process Tool.
Function block data Receive All Blocks (Block Model
exchange 461) and Send All Blocks (Block
Model 462)
Contact signal data Contact Distributor block (Block Model 201) + Internal Switch block
exchange (Block Model 209)
Analog signal data Input Selector block (Block Model 162) and Constant Generator
exchange block (Block Model 166)
Function Block Data:
CSV tags are set in the CX-Process Tool by selecting the function
blocks and then selected Settings – Tag Setting – CSV Tags.
Contact Signals:
tags for Monitor Plus are set for each contact in the Internal Switch
blocks. The function blocks are then selected, the right mouse button
clicked, and Tag Setting – Monitor Plus Tag is selected.
Analog Signals:
tags for Monitor Plus are set for each analog signal in the Variable
ITEM Setting and Constant Generator blocks. The function blocks
are then selected, the right mouse button clicked, and Tag Setting –
Monitor Plus Tag is selected.
Start the CX-Monitor Plus and click the Run or Setup Button.
Using CX-Process Monitor Plus, you can monitor and set only the data given
above to which tag names have been allocated. Also, be sure to use CX-Pro-
cess Tool to make tag name settings.
Loop Control Unit
Control Blocks:
Basic PID (Block Model 011), Advanced PID (Block Model
012), Blended PID (Block Model 013), Batch Flowrate Capture
(Block Model 014), Indication and Setting (Block Model 031),
Indication and Operation (Block Model 032), Ratio Setting
(Block Model 033), Indicator (Block Model 034), 2-position
ON/OFF (Block Model 001), and 3-position ON/OFF (Block
Model 002)
Operation Blocks:
High/Low Alarm (Block Model 111), Segment Program 2
(Block Model 157), ON/OFF Valve Manipulator (Block Model
221), Motor Manipulator (Block Model 222), Reversible Motor
Manipulator (Block Model 223), Motor Opening Manipulator
(Block Model 224), Timer (Block Model 205) and Counter
(Block Model 208)
Contact signals through Contact Distributor (Block Model 201)
+ Internal Switch (Block Model 209)
Analog signals through Input Selector (Block Model 162)
Analog signals through Constant Generator (Block Model 166)
Loop Control Unit
Section 1-1
Loop Control Board
Loop Control Board
HMI functions in the System
Common block (Block Model
000)
