Control Screens

Screen Selection Buttons
4-7

Control Screens

4-7-1

Outline

Block name (mode)
Target function block
Display
Setting
82
Button name
Overview
Alarm
Operation Log
Operation Guide
System Monitor
System Monitor Log Displays the System Monitor Log Screen, which registers sys-
About
External applica-
tion start buttons
Use Control Screens to monitor and set the Control Block and part of the
Operation Block, to monitor analog signals, and to monitor and set contact
signals. For the Control Block in particular, use the Control screen to perform
such operations as monitoring Set Point (SP), Process Variable (PV), Manipu-
lated Variable (MV) run status, and Set Point (SP) changes, etc.
Click the Control Screen Button in the Overview screen to display the follow-
ing information on the Control Screen.
• You can display up to a maximum of eight loops per screen of PID, Indica-
tors, and other Control Blocks as on-site Instrument images. The maxi-
mum is 400 screens x eight loops.
• You can perform SP changes, auto/manual switching, and manual opera-
tions, etc. (Items indicated by a Button can be changed. Items without a
Button are displayed only.)
• You can also move to the Tuning Screen.
Control Blocks: Basic PID (011), Advanced PID (012), Blended PID (Block Model 013), Batch
Flowrate Capture (Block Model 014), Indication and Setting (031), Indication and Operation
(032), Ratio Setting (033), Indicator (034), 2-position ON/OFF (001), 3-position ON/OFF (002)
Operation Blocks: High/Low Alarm (111), Segment Program 2 (157), ON/OFF Valve Manipula-
tor (221), Motor Manipulator (222), Reversible Motor Manipulator (223), Motor Opening Manip-
ulator (224), Timer (205), Counter (208)
The following for all function blocks:
Analog input signals (Input Selector (Block Model 162))
Analog output signals (Constant Generator (Block Model 166))
Contact input signals or contact output signals for all function blocks, or contact value parame-
ters (Contact Distributor (Block Model 201) + Internal Switch (Block Model 209))
SP, PV, MV, A/M status, R/L status (See note 1), bar color change analog signal when an alarm
occurs, contact signal
SP, MV (only in manual mode), A/M switching (See note 3), R/L switching (See notes 1 and 2.)
Contact signal (See note 4.)
Displays the Overview Screen. If multiple Overview Screens
are registered, a pull-down menu will be displayed from which
you can select the Overview Screen you want.
Displays the Alarm Log Screen.
Displays the Operation Log Screen.
Displays the Operation Guide Screen.
Displays the System Monitor Screen to show system status.
tem messages.
Displays information on the CX-Process Monitor Plus version.
Start external applications set in the System Info.
Send source function block, or ITEM
Section 4-7
Function
