Omron CX-PROCESS MONITOR PLUS V2 - 01-2007 Operation Manual page 203

Screen Configuration
Saving to an CSV File
188
The Trend Screen will be registered, and the name of the screen you en-
tered will be displayed in the Screen Management Tree.
Automatically saving to an CSV file is described below.
To automatically save a CSV file, check Autosave enable on the above screen
and then make the following settings.
Interval (hours)
The time can be set to 1, 2, 3, 4, 6, 10, 12, 18, 20, 24, 48, 72, 86, 120, or 240
hours. The default for Real Time Trends is 12 hours, and the default for Histor-
ical Trends is 240 hours.
Folder
Specify the folder in which to save the file. The Browse Button can be use to
simplify setting the folder.
Filename
Specify the name of the file to save. Do not specify the file name extension.
The actual name of the file that is saved will be as follows:
filename_data_time.csv
For example, if a file called RealTimeTrend is saved at 16:15:10 on December
1 2006, the file name RealTimeTrend_20061201_161510.csv will be created
automatically.
Section 5-5
