Return The Server To The Normal Rack Position - Oracle Exadata X10M Service Manual

Lift the server from the antistatic mat, and reinstall the server into the rack.
1.
See
If the cable management arm (CMA) is not installed, because you removed the
2.
server completely out of the rack, install the CMA.
See
If the cables are disconnected from the back of the server, because you removed
3.
the server completely out of the rack, reconnect the cables.
•
•

Return the Server to the Normal Rack Position

If the server is in the extended maintenance position, use this procedure to return the
server to the normal rack position.
Push the server back into the rack, as described in the following steps.
1.
a.
Rackmounting the Server.
Install the Cable Management Arm
For instructions to reconnect cables to the back of the server, see
Power and Data Cables.
To identify the location of cable connectors on the back of the server, refer to
Back Panel Connector Locations.
Simultaneously pull and hold the two green release tabs (one on each side of
the slide rails on the server) toward the front of the server, while you push the
server into the rack.
Verify that the cable management arm (CMA) retracts without binding.
Note:
To pull the green release tab, place your finger in the center of the
tab, not on the end, and apply pressure as you pull the tab toward
the front of the server.
Return the Server to the Normal Rack Position
(Optional).
Chapter 17
Reconnect
17-4
