Bit Hex Dec
16 10000 65536
17 20000 131072
18 40000 262144
19 80000 524288
20 100000 1048576
21 200000 2097152
22 400000 4194304
23 800000 8388608
24 1000000 16777216
25 2000000 33554432
26 4000000 67108864
27 8000000 134217728
28 10000000 268435456
29 20000000 536870912
30 40000000 1073741824
31 80000000 2147483648

5.3 Warning Words

Table 472: Warning Words
Bit Hex Dec
0 1 1
1 2 2
2 4 4
3 8 8
4 10 16
5 20 32
6 40 64
7 80 128
8 100 256
9 200 512
10 400 1024
11 800 2048
12 1000 4096
194 | Danfoss A/S © 2021.07
Parameter 16-90 Alarm Word
Live zero error
Internal fault
0
U phase loss
V phase loss
W phase loss
0
Control voltage fault
0
VDD1 supply low
0
0
Earth fault
Drive initialized
0
0
Parameter 16-92 Warning Word
0
Pwr.card temp
Earth fault
0
Ctrl. word TO
Over current
0
Motor th. over
Motor ETR over
Inverter overld.
DC under volt
DC over volt.
0
Troubleshooting
Parameter 16-91 Alarm Word 2
0
0
Fans error
0
0
0
0
0
0
0
0
0
0
0
0
0
Parameter 16-93 Warning Word 2
0
0
0
0
0
No flow
0
0
Broken belt
0
0
0
0
