VLT® Flow Drive FC 111
Programming Guide
Table 6: Setup Wizard for Open-loop Applications
Parameter Option
Parameter 0-03
[0] International
Regional Set-
[1] US
tings
Parameter 0-06
[10] 380–440 V/50 Hz/IT-grid
GridType
[11] 380–440 V/50 Hz/Delta
[12] 380–440 V/50 Hz
[20] 440–480 V/50 Hz/IT-grid
[21] 440–480 V/50 Hz/Delta
[22] 440–480 V/50 Hz
[110] 380–440 V/60 Hz/IT-grid
[111] 380–440 V/60 Hz/Delta
[112] 380–440 V/60 Hz
[120] 440–480 V/60 Hz/IT-grid
[121] 440–480 V/60 Hz/Delta
[122] 440–480 V/60 Hz
Parameter 1-10
*[0] Asynchron
Motor Con-
[1] PM, non-salient SPM
struction
[3] PM, salient IPM
Danfoss A/S © 2021.07
Default Usage
–
[0] Interna-
tional
Size related Select the operating mode for restart after reconnection of
the drive to mains voltage after power down.
Compared to 380–440 V groups, when selecting 440–
480 V groups, the rated current decreases accordingly.
Setting the parameter value might change these parame-
[0] Asynchron
ters:
•
Parameter 1-01 Motor Control Principle.
•
Parameter 1-03 Torque Characteristics.
•
Parameter 1-08 Motor Control Bandwidth.
• Parameter 1-14 Damping Gain.
• Parameter 1-15 Low Speed Filter Time Const.
• Parameter 1-16 High Speed Filter Time Const.
• Parameter 1-17 Voltage Filter Time Const.
•
Parameter 1-20 Motor Power.
•
Parameter 1-22 Motor Voltage.
•
Parameter 1-23 Motor Frequency.
•
Parameter 1-24 Motor Current.
•
Parameter 1-25 Motor Nominal Speed.
•
Parameter 1-26 Motor Cont. Rated Torque.
• Parameter 1-30 Stator Resistance (Rs).
• Parameter 1-33 Stator Leakage Reactance (X1).
• Parameter 1-35 Main Reactance (Xh).
• Parameter 1-37 d-axis Inductance (Ld).
•
Parameter 1-38 q-axis Inductance (Lq).
•
Parameter 1-39 Motor Poles.
•
Parameter 1-40 Back EMF at 1000 RPM.
•
Parameter 1-44 d-axis Inductance Sat. (LdSat).
•
Parameter 1-45 q-axis Inductance Sat. (LqSat).
•
Parameter 1-46 Position Detection Gain.
• Parameter 1-48 Current at Min Inductance for d-axis.
• Parameter 1-49 Current at Min Inductance for q-axis.
• Parameter 1-66 Min. Current at Low Speed.
Programming
N O T I C E
