VLT® Flow Drive FC 111
Programming Guide
4.2.2 0-1* Define and Setup Operations
A complete set of all parameters controlling the drive is called a setup. A fixed set of factory settings can be copied into 1 or more
setups.
Some of the advantages of having more than 1 setup in the drive are:
• Run the motor in 1 setup (active setup) while updating parameters in another setup (edit setup).
• Connect the 2 motors (1 at a time) to the drive. Motor data for the 2 motors can be placed in the 2 setups.
• Rapidly change settings of the drive and/or the motor while the motor is running. For example, ramp time or preset references
via bus or digital inputs.
The active setup can be set as multi setup, where the active setup is selected via input on a digital input terminal and/or via the bus
control word.
To copy a setup to other setup, use parameter 0-51 Set-up Copy. To avoid conflicting settings of the same parameter within different
setups, link the setups using parameter 0-12 Link Setups. Stop the drive before switching between setups where parameters marked
not changeable during operation have different values.
0-10 Active Set-up
Default value: [1] Set-up 1
Conversion index: -
Select the setup to control the drive functions. Use Multi setup for remote selection.
Table 18: Option:
[1] Set-up 1 Setup 1 is active.
[2] Set-up 2 Setup 2 is active.
[9] Multi Setup Used for remote setup selections via digital inputs and the serial communication port. This setup uses the
settings from parameter 0-12 Link Setups.
0-11 Programming Set-up
Default value: [9] Active Set-up
Conversion index: -
Select the setup to be edited. It indicates the setup being programmed by LCP when it is accessed by LCP. It indicates the setup
being programmed by RS485 when accessed by RS485, and so on for other channels like fieldbus, USB, and so on.
Table 19: Option:
[1] Set-up 1
[2] Set-up 2
[9] Active Set-up
0-12 Link Setups
Default value: [20] Linked
Conversion index: -
If the setups are not linked, a change between them is not possible while the motor is running.
Table 20: Option:
[0] Not linked When selecting a different setup for operation, the setup change does not occur until the motor is coasted.
[20] Linked
Copy not changeable during operation parameters from 1 setup to the other. It is possible to switch setups
while the motor is running.
34 | Danfoss A/S © 2021.07
Parameter type: Option
Data type: u_int8
Parameter type: Option
Data type: u_int8
Edit setup 1.
Edit setup 2.
Edit parameters in the setup selected via digital I/Os.
Parameter type: Option
Data type: u_int8
2-setup: 1 setup
Change during operation: True
2-setup: 1 setup
Change during operation: True
2-setup: All setups
Change during operation: False
AU363928304090en-000101 / 130R0982
Parameters
