VLT® Flow Drive FC 111
Programming Guide
5-01 Terminal 27 Mode
Default value: [0] Input
Conversion index: -
Table 129: Option:
[0] Input
[1] Output
5-02 Terminal 29 Mode
Default value: [0] Input
Conversion index: -
Table 130: Option:
[0] Input
[1] Output
5-03 Digital Input 29 Mode
Default value: [0] PNP
Conversion index: -
Table 131: Option:
[0] PNP
[1] NPN
4.7.2 5-1* Digital Inputs
Parameters for configuring the input functions for the input terminals. The digital inputs are used for selecting various functions in
the drive.
Table 132: Selected Preset Reference (Parameter 3-10 Preset Reference)
Selected preset reference:
Preset reference 0
Preset reference 1
Preset reference 2
Preset reference 3
Preset reference 4
Preset reference 5
Preset reference 6
Preset reference 7
Danfoss A/S © 2021.07
Parameter type: Option
Data type: u_int8
Define terminal 27 as a digital input.
Define terminal 27 as a digital output.
Parameter type: Option
Data type: u_int8
Define terminal 29 as a digital input.
Define terminal 29 as a digital output.
Parameter type: Option
Data type: u_int8
Set to PNP mode for digital inputs 29.
Set to NPN mode for digital inputs 29.
Preset reference bit 2
0
0
0
0
1
1
1
1
2-setup: All setups
Change during operation: True
2-setup: All setups
Change during operation: True
2-setup: 1 setup
Change during operation: False
Preset reference bit 1
0
0
1
1
0
0
1
1
AU363928304090en-000101 / 130R0982 | 69
Parameters
Preset reference bit 0
0
1
0
1
0
1
0
1
