VLT® Flow Drive FC 111
Programming Guide
Parameter Range
-4999.000–4999.000
Parameter 3-03
Maximum Ref-
erence
Parameter 3-10 -100–100%
Preset Refer-
ence
0.05–3600.0 s
Parameter 3-41
Ramp 1 Ramp
Up Time
Parameter 3-42 0.05–3600.0 s
Ramp 1 Ramp
Down Time
0.0–400.0 Hz
Parameter 4-12
Motor Speed
Low Limit [Hz]
Parameter 4-14 0.0–400.0 Hz
Motor Speed
High Limit [Hz]
0.0–400.0 Hz
Parameter 4-19
Max Output
Frequency
0.00–10.00 V
Parameter 6-20
Terminal 54
Low Voltage
Parameter 6-21 0.00–10.00 V
Terminal 54
High Voltage
0.00–20.00 mA
Parameter 6-22
Terminal 54
Low Current
Parameter 6-23 0.00–20.00 mA
Terminal 54
High Current
-4999–4999
Parameter 6-24
Terminal 54
Low Ref./Feedb.
Value
Parameter 6-25 -4999–4999
Terminal 54
High Ref./
Feedb. Value
Parameter 6-26 0.00–10.00 s
Terminal 54 Fil-
ter Time Con-
stant
Danfoss A/S © 2021.07
Default Usage
The maximum reference is the highest value obtainable by
50
summing all references.
0 Enter the setpoint.
Size related
Ramp-up time from 0 to rated parameter 1-23 Motor Frequen-
cy for induction motors. Ramp-up time from 0 to parameter
1-25 Motor Nominal Speed for PM motors.
Size related Ramp-down time from rated parameter 1-23 Motor Frequency
to 0 for induction motors. Ramp-down time from parameter
1-25 Motor Nominal Speed to 0 for PM motors.
Enter the minimum limit for low speed.
0.0 Hz
100 Hz Enter the minimum limit for high speed.
100 Hz Enter the maximum output frequency value. If parameter
4-19 Max Output Frequency is set lower than parameter 4-14
Motor Speed High Limit [Hz], parameter 4-14 Motor Speed High
Limit [Hz] is set equal to parameter 4-19 Max Output Frequen-
cy automatically.
Enter the voltage that corresponds to the low reference val-
0.07 V
ue.
10.00 V Enter the voltage that corresponds to the high reference val-
ue.
Enter the current that corresponds to the low reference val-
4.00 mA
ue.
20.00 mA Enter the current that corresponds to the high reference val-
ue.
Enter the feedback value that corresponds to the voltage or
0
current set in parameter 6-20 Terminal 54 Low Voltage/param-
eter 6-22 Terminal 54 Low Current.
50 Enter the feedback value that corresponds to the voltage or
current set in parameter 6-21 Terminal 54 High Voltage/pa-
rameter 6-23 Terminal 54 High Current.
0.01 Enter the filter time constant.
Programming
